Configuring the video display

Procedure
1. From the System Utilities screen, select System Configuration > BIOS/Platform Configuration
(RBSU) > Advanced Options > Video Options and press Enter.
2. Select a setting and press Enter.
a. Add-in Video Enabled, Embedded Video Disabled—The system only displays video to the first
discovered add-in video controller.
b. Both Add-in and Embedded Video Enabled—The system displays video to the embedded and the
first discovered add-in video controller.
3. Press F10.

Embedded Video Connection

Use this option to configure an external video connection to the embedded video connection. By default, the
external video connection to the embedded video controller is automatically disabled to save power when a
monitor is not attached. It is enabled automatically when a monitor is attached (including when the server is
operating).

Configuring an embedded video connection

Procedure
1. From the System Utilities screen, select System Configuration > BIOS/Platform Configuration
(RBSU) > Advanced Options > Embedded Video Connection and press Enter.
2. Select a setting and press Enter.
a. Auto—The external video connection to the embedded video controller is automatically disabled to
save power when a monitor is not attached. It is enabled automatically when a monitor is attached
(including when the server is operating).
b. Always Disabled—The external video connection to the embedded video controller is disabled and a
monitor connected to this port does not display except during system boot.
c. Always Enabled—The external video connection to the embedded video controller is always enabled.
This option is only required if a monitor is attached with a monitor detection that does not function,
causing Auto mode not to work properly.
3. Press F10.

Fan and Thermal Options

• Thermal Configuration
• Thermal Shutdown
• Fan Installation Requirements
