3.
After mounting, the panel should appear as shown in the figure below. Then at
the rear of the machine, lock the hook screw to fix the machine in place.
Note!
According to the quick installation guide, the recommended mount thick-
ness is no more than 2 mm (0.079 in). For other situations, the recom-
mended thickness is 6 mm or less (0.236 in).
39
PPC-6151C/6171C/6191C User Manual
