2.3.3

Check and Adjust Jumpers on the Motherboard

The image below shows the PPC-MB-8260AE motherboard with PPC-6151C-RTAE.
JP7
JP3
JP4
JP5
PPC-6151C/6171C/6191C User Manual
Resolution
LED panel PWR
Backlight level
Brightness PWM level
14
1024 x 768 (24 bit)
+3.3 V
+3.3 V
+3.3 V
