2.1

Anti-Static Precautions

Warning! Failure to take appropriate ESD precautions during maintenance may
result in permanent damage to the PPC and severe injury to the user.
Electrostatic discharge (ESD) can cause serious damage to electronic components,
including the PPC model. ESD is especially common in dry climates. Therefore,
when manually handling or accessing any of the PPC model's internal components,
anti-static precautions should be strictly followed.
Always wear an anti-static wristband when handling the PPC model; this can prevent
ESD from damaging the board or causing personal injury.
Note! Refer to Chapter 1.3 (Chassis Comparison) to determine the chassis
type, then refer to Chapters 2.3 and 2.4 (for PPC-6151C/6171C/6191C-
RTAE and PPC-6151C/6171C/6191C-RMAE, respectively) for the
installation guidelines.
2.2

Installation Procedures

The procedures listed below must be followed to ensure correct installation.
2.3 PPC-6151C/6171C/6191C-RTAE Motherboard Installation
Remove the back cover
Remove the reinforced bracket
Check and adjust the jumpers on the PPC-MB-8260AE motherboard
Install the PPC-MB-8260AE motherboard
Connect the motherboard wires
2.4 PPC-6151C/6171C/6191C-RMAE Motherboard Installation
Remove the back cover
Remove the reinforced bracket
Check and adjust jumper settings
Install the Mini-ITX motherboard (AIMB-275)
Connect the motherboard wires
Connect the daughter board and motherboard with a cable
2.5 Component Setup
CPU installation
CPU cooler installation
Memory card installation
HDD installation
Wi-Fi module installation
Expansion card installation
Rear cover installation
PPC-6151C/6171C/6191C User Manual 12
2.3.1
2.3.2
2.3.3
2.3.4
2.3.5
2.4.1
2.4.2
2.4.3
2.4.4
2.4.5
2.4.6
2.5.1
2.5.2
2.5.3
2.5.4
2.5.5
2.5.6
2.5.7
