User Manual
PPC-3100S/3120S
Intel® Celeron® N2930 Processor
based panel PC, with 10"/12" color
TFT LCD display

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PPC-3100S and is the answer not in the manual?

Questions and answers

Related Manuals for Advantech PPC-3100S

Summary of Contents for Advantech PPC-3100S

  • Page 1 User Manual PPC-3100S/3120S Intel® Celeron® N2930 Processor based panel PC, with 10"/12" color TFT LCD display...
  • Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.

  • Page 3: Declaration Of Conformity

    This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information.

  • Page 4: Safety Instructions

    The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
  • Page 5 Do not attempt to recharge, force open, or heat the battery. Replace the battery only with the same or equivalent type recommended by the man- ufacturer. Discard used batteries according to the manufacturer's instructions. Note! Notes provide optional additional information. Revision Date Version Description/Change May 2016 Initial PPC-3100S/3120S User Manual...
  • Page 6 PPC-3100S/3120S User Manual...

  • Page 7: Table Of Contents

    Figure 1.2 Rear panel of PPC-31x0S .......... 3 Bottom Side....................3 Figure 1.3 Bottom side of PPC-31x0S......... 3 Dimensions ....................4 Figure 1.4 PPC-3100S dimension ..........4 Figure 1.5 PPC-3120S dimension ..........4 Specifications .................... 5 1.7.1 Specification Comparison ............. 5 Ordering Information .................
  • Page 8 Appendix A BSMI RoHS ........45 BSMI RoHS..................... 46 Appendix B China ROHS........47 China ROHS ................... 48 Appendix C E-eye Function ........49 E-eye Function..................50 Table C.1: PPC E-eye Monitoring Function List ......50 PPC-3100S/3120S User Manual viii...
  • Page 9 Appendix D Watchdog Timer Programming Example51 Watchdog Timer Programming Example ..........52 PPC-3100S/3120S User Manual...
  • Page 10 PPC-3100S/3120S User Manual...

  • Page 11: Chapter 1 General Information

    Chapter General Information This chapter gives background information on PPC-3100S/3120S panel PC. Sections include:  Introduction  Specifications  Dimensions...

  • Page 12: Introduction

    Supports one USB 3.0  Supports E-eye monitoring and protection function in rear panel Front Panel The front side of PPC-3100S/3120S is a flat panel LCD with touch screen, which pro- vides IP65 protection. (Figure 1.1) Touch Screen Aluminum Frame...

  • Page 13: Rear Panel

    1 x Power switch  1 x RS-232 connector (COM1)  1 x RS-232/422/485 connector (COM2)  2 x RJ45 GbE  1 x USB 3.0  2 x USB 2.0 Figure 1.3 Bottom side of PPC-31x0S PPC-3100S/3120S User Manual...

  • Page 14: Dimensions

    Dimensions Figure 1.4 PPC-3100S dimension PPC-3120S dimensions drawing as below: Figure 1.5 PPC-3120S dimension PPC-3100S/3120S User Manual...

  • Page 15: Specifications

    2Grms with SSD, following IEC 60068-2-64 IP Level IP65 Safety: CE, UL, CCC, BSMI Safety and EMC EMC: CE, FCC Class B, BSMI Dimensions 272 x 217 x 46mm 317 x 246 x 49mm Weight 1.9 kg 2.1 kg PPC-3100S/3120S User Manual...

  • Page 16: Ordering Information

    Panel PC with Intel Celeron® N2930 PPC-3120S-RAE processor Bracket model for 2.5" SSD/HDD instal- PPC-3100S-HDDE lation Power adapter AC100 ~ 240V, 65W, PS-DC19-65AE PPC-WLAN-A1E Wi-Fi module with antenna PPC-ARM-A03 ARM VESA standard PPC-174T-WL-MTE Wall mount kit PPC-Stand-A1E Stand kit PPC-3100S/3120S User Manual...

  • Page 17: Chapter 2 System Installation & Setup

    Chapter System Installation & Setup Sections include:  Quick Installation Guide  Install Memory Card  Install ODD  Install HDD  Install mSATA  Install Wireless LAN Card  Mounting the System...

  • Page 18: Quick Start Guide

    When you place the panel PC upright on the desktop, its front panel appears as shown in Figure 2.1, Backside View shown in Figure 2.2 and I/O Connectors shown in Figure 2.3. Figure 2.1 Frontside View Figure 2.2 Backside View PPC-3100S/3120S User Manual...

  • Page 19: Installing Procedures

    Mount the Panel PC Configure the system 2.2.1 Installing Memory Card Remove seven retention screws and pull out the cable, then take off the rear cover. (See Figures 2.4 and 2.5) Figure 2.4 Retention screw on rear cover PPC-3100S/3120S User Manual...

  • Page 20: Figure 2.5 Remove Cable From Mainboard

    Insert the memory card into the slot as indicated in the red square below, and attach the thermal pad for the memory from the accessory box, then the installa- tion of the memory card is finished. (See Figure 2.6 and 2.7) Figure 2.6 Install memory card PPC-3100S/3120S User Manual...

  • Page 21: Install Hdd

    Warning! Please make sure the thermal pad (in the accessory box) attached on the memory surface as figure 2.7. 2.2.2 Install HDD Remove the preinstalled four retention screws on HDD bracket. (See Figure 2.8) Figure 2.8 Retention screw on HDD bracket PPC-3100S/3120S User Manual...

  • Page 22: Figure 2.9 Hdd Module

    Figure 2.9 HDD Module Get SATA cable from the accessory box and connect it to the SATA HDD. (See Figure 2.9) Figure 2.10 Connection of cable and SATA HDD PPC-3100S/3120S User Manual...

  • Page 23: Figure 2.11Secure Sata Hdd With Screws

    Figure 2.11 Secure SATA HDD with screws Locate and secure the SATA HDD module, and tie the SATA power cable, then plug the cable into the M/B corresponding connector. (See Figure 2.11) Figure 2.12 Connect SATA HDD to Mainboard PPC-3100S/3120S User Manual...

  • Page 24: Installing Msata

    Insert the Mini PCIe full size card into socket, and secure the card with the two retention screw in accessory box. And replace the original bracket with holed antenna bracket in accessory box. (See Figure 2.13) Figure 2.14 Install wireless LAN card PPC-3100S/3120S User Manual...

  • Page 25: Figure 2.15Location Of Retention Screw

    Insert the mini PCIe half size card into socket at an angle, and secure with a screw from the accessory box. And replace the original bracket with holed antenna bracket in accessory box.(See Figure 2.15) Figure 2.16 Secure the half-size mini PCIe card PPC-3100S/3120S User Manual...

  • Page 26: Figure 2.17Antenna Cables Of Full-Size Mini Pcie Lan Module

    Figure 2.17 Antenna cables of Full-size mini PCIe LAN module Figure 2.18 Antenna cables of Half-size mini PCIe LAN module Remove the two plugs on top of the rear cover. (See Figure 2.18) Figure 2.19 Remove plugs for antenna PPC-3100S/3120S User Manual...

  • Page 27: Figure 2.20Reinstall The Rear Cover

    Connect the cable to the Mainboard, then secure the rear cover. (See Figure 2.19) Figure 2.20 Reinstall the rear cover Install the external antenna. (See Figure 2.20) Figure 2.21 Location of external antenna PPC-3100S/3120S User Manual...

  • Page 28: Mounting The System

    Drill two pilot holes at the marked locations on the wall Align the wall-mounting bracket screw holes with the pilot holes. Secure the mounting-bracket to the wall by inserting the retention screws into the two pilot holes and tightening them. Figure 2.22 Mounting bracket on the wall PPC-3100S/3120S User Manual...

  • Page 29: Figure 2.23Location Of Four Screws On Rear Panel

    Figure 2.23 Location of four screws on rear panel Warning! Please make sure the thread depth of the screw for rear panel should be not more than 4mm. Align the Panel PC into the mounting bracket on the wall. (Figure 2.23) Figure 2.24 PPC-3100S/3120S User Manual...

  • Page 30: Panel Mounting

    To mounting the flat bezel panel PC into a panel, please follow the steps below. Cut out a section corresponding to the size shown below. The dimensions unit is mm. (See Figure 2.21) (See Figure 2.22) (See Figure 2.23) Figure 2.26 PPC-3100S Cut-out dimension PPC-3100S/3120S User Manual...

  • Page 31: Figure 2.27Ppc-3120S Cut-Out Dimension

    Figure 2.27 PPC-3120S Cut-out dimension Put the machine into the cabinet and take out eight Hook Brackets from the accessory box. (See Figure 2.24) Figure 2.28 Hooks bracket for panel mounting PPC-3100S/3120S User Manual...

  • Page 32: Figure 2.29Hooks Bracket Location

    Put the Hook Brackets into the holes according to the arrow and hookup machine. (See Figure 2.25) Figure 2.29 Hooks bracket location Lock screws and fixed machine. (See Figure 2.26) Figure 2.30 Fasten the Hook bracket PPC-3100S/3120S User Manual...

  • Page 33: Arm Mounting

    PC, and secure the panel PC by four M4 retention screws. (see Fig- ure 2.28) Figure 2.32 Arm mounting Warning! Please make sure the thread depth of the screw for rear panel should be not more than 4mm. PPC-3100S/3120S User Manual...

  • Page 34: Stand Mounting

    As shown in the figure below use 4 screws of No. A in pack list to lock the VESA BKT to the machine. Depending on your needs, you can choose between using 75*75 mm or 100*100 mm of VESA mount. Figure 2.33 Screw Holes PPC-3100S/3120S User Manual...

  • Page 35: Figure 2.34Securing Base

    As the figure below shows, use 4 screws of No. A in pack list to lock on the base plate. Figure 2.34 Securing Base As the figure below shows use 4 screws of No. B in the pack list to secure the VESA Bracket. Figure 2.35 Securing VESA Bracket PPC-3100S/3120S User Manual...

  • Page 36: Figure 2.36Securing Hinge Cover

    As the figure below shows, use 1 x No. C screw in the pack list to secure the hinge cover. Figure 2.36 Securing Hinge Cover Completed view of stand mounting a PPC machine Figure 2.37 Complete Stand Mount View PPC-3100S/3120S User Manual...

  • Page 37: Jumper Setting

    Chapter Jumper Setting Sections include:  Jumpers & Connectors  External COM Ports and Pin Definitions...

  • Page 38: Motherboard Layout Diagram

    LVDS power select jumper Pin header 3P 2.54mm RTC select jumper Pin header 4P 2.0mm ATX/AT select jumpwer Pin header 3P 2.0mm LVDS PWM power select jumper Pin header 3P 2.0mm LVDS enable power select jumper Pin header 3P 2.0mm PPC-3100S/3120S User Manual...

  • Page 39: Lvds Power Select Jumper

    LVDS PWM Power Select Jumper (1-2) (2-3) 3.3V Default* 3.2.3 LVDS enable power select jumper Icon LVDS Enable Power Select Jumper (1-2) (2-3) 3.3V Default* 3.2.4 RTC select Icon RTC Select (2-3) Normal Default* (3-4) Clear CMOS PPC-3100S/3120S User Manual...

  • Page 40: Com1 Pin 9 Select

    COM1 PIN9 Power Select (1-2) COM1 RI Default* (2-3) COM1 PIN9 5V (4-5) COM1 PIN9 12V 3.2.6 ATX/AT select Icon ATX/AT Select (1-2) (2-3) Default* External COM Ports and Pin Definitions Figure 3.2 COM1 and COM2 Position PPC-3100S/3120S User Manual...
  • Page 41 COM1 Pin9 is set as RI signal by default and also can be set as 5 V or 12 V output via jumper setting. COM2: RS232/422/485 Note! COM2 does not support RING function. COM1 COM2 RS232 RS232 RS422 RS485 DATA- DATA+ RING or 5V/12V Output RING PPC-3100S/3120S User Manual...
  • Page 42 PPC-3100S/3120S User Manual...

  • Page 43: Software Setup

    Chapter Software Setup Sections include:  Installing Drivers  BIOS Setup Program...

  • Page 44: Installing Divers

    When entering the BIOS menu, select "Advanced → Security configuration → TXE HMRFPO → enable". Figure 4.1 Restart the computer. Execute AFUDOS 8211BIOS.bin /P /B /N /X /ME. Power on the system again after it is powered off. The BIOS is then updated. PPC-3100S/3120S User Manual...

  • Page 45: Entering Bios Setup

    When the power is turned on, press the <Del> button to enter BIOS setup screen. Whenever a change is made, press <F4> to save and exit; otherwise the settings will not be saved in the BIOS. 4.2.3 Adjustment of LCD Brightness Select “Host Bridge” in “Chipset” tab. PPC-3100S/3120S User Manual...
  • Page 46 Then select “Intel IGD Configuration”. Select “Brightness Manual Control” and there will be six brightness levels to choose. PPC-3100S/3120S User Manual...

  • Page 47: Com2 Mode Selection (Rs232/Rs422/Rs485)

    4.2.4 COM2 Mode Selection (RS232/RS422/RS485) Select “NCT5523D Super IO Configuration” in the “Advanced” tab. Select "Serial Port 2 Configuration" and then click PPC-3100S/3120S User Manual...
  • Page 48 Select "Serial Port 2 Mode" and then click to select COM2 operation mode [RS232] or [RS422] or [RS485]. When COM2 Mode is selecting RS485, “Auto Flow Control” also can select [Enabled] or [Disabled] PPC-3100S/3120S User Manual...

  • Page 49: Os Selection

    When COM2 Mode is selecting RS485, “Serial Port2 Terminal” also can select [Enabled] or [Disabled] 4.2.5 OS Selection Select “South Bridge” in the “Chipset” tab. PPC-3100S/3120S User Manual...

  • Page 50: Bios At & Atx Setup

    Different OSs can be selected through “OS Selection” [Windows 7]/[Android]/ [Windows 8.X] Note! “OS Selection" is preset as Windows 7, which needs to be changed when Windows 8.X or Android OS is installed. 4.2.6 BIOS AT & ATX Setup Select "South Bridge" in the "Chipset" tab. PPC-3100S/3120S User Manual...

  • Page 51: Wake On Lan

    In “Restore AC Power Loss”, set “Power On” to “AT” and “Power Off” to “ATX”. 4.2.7 Wake on LAN Select "South Bridge" in the "Chipset" tab. PPC-3100S/3120S User Manual...

  • Page 52: Sata Mode Selection

    Set “Wake on Function” to “Enabled”. 4.2.8 SATA Mode Selection Select "IDE Configuration" in the "Advanced" tab. PPC-3100S/3120S User Manual...

  • Page 53: Boot Options

    Select “SATA Mode”. 4.2.9 Boot Options Select "CSM Configuration" in the "Advanced" tab. PPC-3100S/3120S User Manual...
  • Page 54 Select “Boot option filter”. Note! Boot option is set as “Legacy only” by default. If “UEFI only” is selected, only Windows 7 64bits or Windows 8.x 64bits can be supported. If UEFI 32bit OS is required, please update BIOS. PPC-3100S/3120S User Manual...

  • Page 55: Bsmi Rohs

    Appendix BSMI RoHS...

  • Page 56: Bsmi Rohs

    BSMI RoHS 設備名稱：電腦 型號 （型式） ：PPC-3100S/PPC-3120S series Equipment name Type designation (Type) 限用物質及其化學符號 Restricted substances and its chemical symbols 多溴聯苯 六價鉻 多溴二苯醚 單元 Unit Polybromina 鎘 Hexavalent Polybrominate 鉛 Lead 汞 Mercury Cadmium chromium d diphenyl (Pb) (Hg) (Cd) biphenyls...

  • Page 57: Appendix B China Rohs

    Appendix China ROHS...

  • Page 58: China Rohs

    China ROHS Dear Customer, Thanks for choosing Advantech Product, to comply with China Electronic Industry Standard SJ/T11364 which require Marking for the Restriction of the Use of Hazard- ous Substances in Electrical and Electronic Products, herein report to you product’s...

  • Page 59: Appendix C E-Eye Function

    Appendix E-eye Function...

  • Page 60: E-Eye Function

    Any of E0~E8 shown by E-eye means there is one or more errors. Values beyond E0~E8 indicates that this may be caused by other dirvers or software If some functions do not work but E-eye shows FF, this is because of the limitation of Self-Diagnosis function of E-eye. PPC-3100S/3120S User Manual...
  • Page 61 Appendix Watchdog Timer Programming Example...
  • Page 62 OUT DX, AL ;set WDT active ;----------------------------------------------------------------------------- ;initial WDT mode ;----------------------------------------------------------------------------- MOV DX, 2EH MOV AL, F0H OUT DX, AL MOV DX, 2FH MOV AL, 00H ; bit0: 0-Pulse Mode, 1- Level mode; bit3: 0- second mode, 1- minute mode; PPC-3100S/3120S User Manual...
  • Page 63 OUT DX, AL MOV DX, 2FH MOV AL, 05H OUT DX, AL ;set time-out value is 5s; 00- time-out disable ;----------------------------------------------- ; Exit the Extended Function Mode ;---------------------------------------------- MOV DX, 2EH MOV AL, AAH OUT DX, AL PPC-3100S/3120S User Manual...
