The image below shows the PPC-MB-8260AE motherboard with PPC-6171C-RTAE.
JP7
JP3
JP4
JP5
The image below shows the PPC-MB-8260AE motherboard with PPC-6191C-RTAE.
JP7
JP3
JP4
JP5
Resolution
LED panel PWR
Backlight level
Brightness PWM level
Resolution
LED panel PWR
Backlight level
Brightness PWM level
15
PPC-6151C/6171C/6191C User Manual
1280 x 1024 (24 bit)
+5 V
+3.3 V
+5 V
1280 x 1024 (24 bit)
+5 V
+3.3 V
+3.3 V
