1. LVDS cable
6. Touch cable
12. Power conn.
Internal complete
connecting picture
Note!
1. The COM cable and DIO cable are the same.
2. The cable connection is based on the motherboard specifications.
2.4
PPC-6151C/6171C/6191C-RMAE Motherboard
Installation
2.4.1
Remove the Back Cover
Unscrew the six screws and remove the rear cover.
PPC-6151C/6171C/6191C User Manual
2. Backlight
3.4. SYS FAN1,2
8.9.10.
7. DIO
COM3,4,5
14 . SPEAKER
13. ATX_5VSB
18
5. HDD cable
11. P ower switch
15. LED cable
