A.1

Riser Card Introduction

A.1.1

PPCB-003 PCI Riser Card

The total current load provided by the PPC-6151C/6171C/6191C PCI slot does not
exceed 20 W. Additional details are provided below.
-12 V
+12 V
+5 V
+3.3 V
+3.3 VSB
A.1.2

PPCB-006 PCIE x4 Riser Card

The total current load provided by the PPC-6151C/6171C/6191C PCI slot does not
exceed 25 W. Additional details are provided below.
+12 V
+3.3 V
+3.3 VSB
PPC-6151C/6171C/6191C User Manual
0.1A
0.5A
4A
2.5A
0.25A
2.1A
3A
0.375A
48
