E3L030 Control module VdS

15 E3L030 Control module VdS
15.1 Overview
15.2 Application
15.3 Key data
60
Siemens Building Technologies
Fire & Security Products
I-Bus module for the connection of VdS peripheral equipment:
FBF Feuerwehr-Bedienfeld: Fire department control panel
ÜE Übertragungseinrichtung: Transmission device
FSD Feuerwehrschlüsseldepot: Fire department key cabinet
SST Standardschnittstelle (VdS) für fremde Lösch-Steuereinrichtung:
Standard interface (VdS) for non-Cerberus extinguishing activating
device
TK Türkontakt Zentrale: Door switch control unit (door open = ÜE disabled)
Connection line to ÜE, FSD and SST monitored
All inputs/outputs to the peripheral equipment with EMI and over voltage protec-
tion
Emergency operation capability
Card format 233 x 200mm
I-Bus address is set at programming switch "S3"
The VdS module is required for connection of the above-mentioned peripheral
equipment.
It is possible to use several VdS modules or one single VdS module for all CPUs
within a C-Bus system.
Restriction: Activation in emergency operation mode would not be possible.
Several VdS modules per CPU would be possible if separate transmission paths
are required for different detector types (automatic/manual).
The VdS module is not FM compliant. It may be used in a ground fault moni-
tored installation, but it is not monitored itself. (For details see chapter 6)
All inputs/outputs are fix allocated (exception LED4)
Line resistance for FBF
Line resistance for FSD
Line resistance for ÜE
Line resistance for SST
Control output load
Quiescent current at 24V
* For details see page 63
max. 5Ω or 20Ω per wire*
max. 5Ω or 50Ω per wire*
max. 10Ω per wire*
max. 10Ω per wire*
max. 40mA with EMI protection
18mA (normal operating mode)
