Connections

K3I110
programmable
control output 1
LED 1
programmable
control output 2
LED 2
programmable
control output 3
LED 3
programmable
control output 4 LED 4
programmable
control output 15
LED 15
programmable
control output 16
LED 16
programmable monitored
control input 1
programmable monitored
control input 2
programmable monitored
control input 3
programmable monitored
control input 4
programmable monitored
control input 13
programmable monitored
control input 14
programmable monitored
control input 15
programmable monitored
control input 16
not used
F1
Supply 9...45VDC
R1
LON-Bus
Siemens Building Technologies
Fire & Security Products
Plug-in terminals X56
1
R1
2
3
R2
4
Plug-in terminals X57
1
R3
2
3
R4
4
Plug-in terminals X63
1
R15
2
3
R16
4
Plug-in terminals X31
1
2
3
4
Plug-in terminals X32
1
2
3
4
Plug-in terminals X37
1
2
3
4
Plug-in terminals X38
1
2
3
4
from E3I040 or from previous LON device
Plug-in terminals K1
1
2
0V
+ 3
4
Earth
5
6
to other LON device
max. 30V / 1A
max. 30V / 1A
A
4k75
B
4k75
1k87
C
4k75
1k87
D
4k75
24V supply
K3I110 LON I/O p.c.b.
Connection of external contact
Contact Monitored on
Application
short circuit
NO NC
A X
B X
C X
D X
007831_a_en_--.doc
X
X
