Siemens FDM223 Technical Manual

Manual call point
Hide thumbs

Advertisement

Quick Links

FDM223, FDM224, FDM223H, FDM224H
Manual call point
Technical Manual
Smart Infrastructure
007002_k_en_--
2019-10-16

Advertisement

loading

  Also See for Siemens FDM223

  Related Manuals for Siemens FDM223

  Summary of Contents for Siemens FDM223

  • Page 1 FDM223, FDM224, FDM223H, FDM224H Manual call point Technical Manual Smart Infrastructure 007002_k_en_-- 2019-10-16...
  • Page 2 All rights created by patent grant or registration of a utility model or design patent are reserved. Issued by: Siemens Switzerland Ltd. Smart Infrastructure Global Headquarters Theilerstrasse 1a CH-6300 Zug Tel. +41 58 724-2424 www.siemens.com/buildingtechnologies Edition: 2019-10-16 Document ID: 007002_k_en_-- © Siemens Switzerland Ltd, 2004 2 | 54 007002_k_en_--...
  • Page 3: Table Of Contents

    Table of contents About this document................. Applicable documents ................Download center..................Technical terms ..................History of changes..................Safety ....................... Safety instructions ..................Safety regulations for the method of operation......... Standards and directives complied with ........... Release Notes ..................Structure and function ................Overview....................
  • Page 4 Installation ....................Installation ....................5.3.1 Mounting the seal FDMP223 ............Installing the protective cover ..............Installing the stickers ................Attaching the window sign ................ Commissioning ..................Localization and device testing..............Checking function ..................Maintenance / Repair ................Resetting after an alarm ................Status query .....................
  • Page 5: About This Document

    Following the instructions consistently will ensure that the product can be used safely and without any problems. Intended use The manual call points FDM223, FDM224, FDM223H, and FDM224H can only be used for the manual activation of fire alarms in a fire detection system FS20 or FS720.
  • Page 6 About this document ID code Examples ID_ModificationIndex_Language_COUNTRY A6V10215123_a_de_DE -- = multilingual or international A6V10215123_a_en_-- A6V10315123_a_--_-- Date format The date format in the document corresponds to the recommendation of international standard ISO 8601 (format YYYY-MM-DD). Conventions for text marking Markups Special markups are shown in this document as follows: ⊳...
  • Page 7: Applicable Documents

    About this document Applicable documents 1.1 Applicable documents Document ID Title 007001 Data sheet Manual call points FDM221, FDM223, FDM224 007227 Technical manual Detector exchanger and tester FDUD292 007905 Installation Housing for manual call point FDMH293-x, FDMH297-R, Switching unit FDME223, FDME224...
  • Page 8: History Of Changes

    About this document History of changes 1.4 History of changes The reference document's version applies to all languages into which the reference document is translated. The first edition of a language version or a country variant may, for example, be version 'd' instead of 'a' if the reference document is already this version.
  • Page 9: Safety

    Safety Safety instructions 2 Safety 2.1 Safety instructions The safety notices must be observed in order to protect people and property. The safety notices in this document contain the following elements: ● Symbol for danger ● Signal word ● Nature and origin of the danger ●...
  • Page 10: Safety Regulations For The Method Of Operation

    2.2 Safety regulations for the method of operation National standards, regulations and legislation Siemens products are developed and produced in compliance with the relevant European and international safety standards. Should additional national or local safety standards or legislation concerning the planning, mounting, installation,...
  • Page 11 Modifications to the system design and the products Modifications to the system and to individual products may lead to faults, malfunctioning and safety risks. Written confirmation must be obtained from Siemens and the corresponding safety bodies for modifications or additions. Modules and spare parts ●...
  • Page 12: Standards And Directives Complied With

    Personal injury or damage to property caused by poor maintenance or lack of maintenance 2.3 Standards and directives complied with A list of the standards and directives complied with is available from your Siemens contact. 2.4 Release Notes Limitations to the configuration or use of devices in a fire detection installation with a particular firmware version are possible.
  • Page 13: Structure And Function

    The manual call points consist of a housing and a switching unit. They have the following features: ● Manual call points FDM223 and FDM223H with indirect activation [➙ 16] ● Manual call points FDM224 and FDM224H with direct activation [➙ 17] ●...
  • Page 14: Details For Ordering

    Structure and function Overview 3.1.1 Details for ordering Design and component combinations: Manual call point Type Order no. Designation Scope of delivery FDM223 FDM224 FDM223H FDM224H Complete device FDM223 A5Q00008098 Red housing (FDMH293-R) with glass insert, (complete) key, switching unit (FDME223), 2 cable grippers...
  • Page 15: Product Version Es

    Structure and function Overview 3.1.2 Product version ES The product version ES provides the technical status of a device in terms of software and hardware. The product version is provided as a two-digit number. You will find the details of your device's product version: ●...
  • Page 16: Setup

    3.2 Setup 3.2.1 Manual call points FDM223H and FDM224H The manual call point FDM223 triggers an alarm when the glass insert is pushed in and the alarm button is pressed (indirect activation). The alarm is immediately transmitted to the control panel.
  • Page 17: Manual Call Points Fdm223H And Fdm224H

    Structure and function Setup 3.2.2 Manual call points FDM223H and FDM224H The manual call point FDM223H triggers an alarm when the glass insert is pushed in and the alarm button is pressed (indirect activation). The alarm is immediately transmitted to the control panel. The manual call point FDM224H triggers an alarm when the glass insert is pushed in.
  • Page 18: Connections

    Structure and function Setup 3.2.3 Connections The manual call points FDM223/FDM224 and FDM223H/FDM224H both have six spring clips on the switching unit for the detector line and connecting external alarm indicators. Figure 5: Switching unit with spring clips 3.2.4 Indication elements An LED is built into the switching unit FDME223/FDME224 as an internal alarm indicator.
  • Page 19: Function

    Structure and function Function 3.3 Function 3.3.1 Danger levels The manual call point can transmit the following danger levels to the control panel: Danger level Meaning Normal state, no danger Alarm The evaluation of the danger level and the resulting measures (e.g. activation of remote transmission) are configured on the control panel.
  • Page 20: Interface To Service Devices

    Structure and function Function 3.3.5 Interface to service devices A proximity interface (MC link) is available for commissioning and maintenance in order to communicate with the detector exchanger and tester FDUD292 and the intelligent detector tester FDUD293. You will find additional information in documents 007227 and 009718. See also Applicable documents [➙...
  • Page 21: Behavior In Degraded Mode

    Structure and function Function 3.3.7 Behavior in degraded mode Applicable for the FDnet/C-NET: When the main processor of the fire control panel fails, the control panel works in degraded mode operation. Depending on the control panel type, the fire control panel can continue to perform the most important alarming and signaling functions in degraded mode operation.
  • Page 22: Accessories

    Structure and function Accessories 3.4 Accessories 3.4.1 Housing for manual call point FDMH293-x ● Housing for use indoors ● Available in the colors red, yellow, green, and blue ● Larger dimensions than the housing FDMH297-R ● Compatible with: – Switching unit FDME223 –...
  • Page 23: Key Dmz1195

    Structure and function Accessories 3.4.4 Key DMZ1195 ● For opening doors on manual call points ● Compatible with: – Manual call point FDM223 – Manual call point FDM224 – Radio manual call point FDM273 ● Order number: BPZ:4851910001 3.4.5 Glass insert DMZ1196-AC ●...
  • Page 24: Seal Dmz1197-Ad

    ● Increases the IP protection category of the manual call points ● Compatible with: – Manual call point FDM223 – Manual call point FDM224 – Manual call point FDM223H – Manual call point FDM224H –...
  • Page 25: M20 X 1.5 Metal Cable Gland

    Structure and function Accessories 3.4.11 M20 x 1.5 metal cable gland ● For introducing a cable into a housing ● For cable diameters of 3.5…5.5 mm ● Temperature range: -40…+100 °C ● Allows for increased IP protection ● Compatible with: – M20 x 1.5 metal counter nut –...
  • Page 26: Planning

    Planning Compatibility FDnet/C-NET 4 Planning 4.1 Compatibility FDnet/C-NET Compatible with control panels that support the FDnet/C-NET detector line. Detector line Control panel FC20xx FC72x SIGMASYS AlgoRex FDnet C-NET – – – X = compatible – = not compatible You will find detailed information in the 'List of compatibility'. See also Applicable documents [➙...
  • Page 27: Mounting / Installation

    From the rear through a specified breakout point a The manual call point FDM223/FDM224 is now prepared for mounting. Figure 7: Opening the door of manual call points FDM223 and FDM224 Manual call points FDM223H and FDM224H (housing FDMH292-R) Cables cannot be inserted though the back of the housing for manual call points FDM223H and FDM224H.
  • Page 28 Mounting / Installation Preparation – Break or cut open the openings for feeding though cables in the cable gripper. – Screw the cable gripper into the housing. 4. Seal off cable entry openings that are not required. a The manual call point FDM223H/FDM224H is now prepared for mounting. Figure 8: Opening the door of manual call points FDM223H and FDM224H 28 | 54 007002_k_en_--...
  • Page 29: Installation

    Observe the country-specific regulations for the exact installation height! Manual call points FDM223 and FDM224 (housing FDMH293-x or FDMH297-R) The manual call point FDM223/FDM224 is prepared for installation. See the chapter 'Preparing the housing'. 1. Secure the housing at a height of 0.9…1.6 m on an even surface.
  • Page 30 Mounting / Installation Installation Manual call points FDM223H and FDM224H (housing FDMH292-R) The manual call point FDM223H/FDM224H is prepared for installation. See the chapter 'Preparation [➙ 27]'. 1. Secure the housing at a height of 0.9…1.6 m on an even surface. – Only use the screw holes marked with arrows (see diagram below). 2.
  • Page 31: Installation

    Only connect one wire per terminal. This is the only way to ensure the connection is failure-free for the entire service life of the device. Connection diagram LINE LINE Ext. AI Figure 13: Connection diagram for manual call points FDM223/FDM224 and FDM223H/FDM224H 007002_k_en_-- 31 | 54...
  • Page 32 Mounting / Installation Installation Connecting the manual call points The manual call point is prepared for electrical connection. See chapters 'Preparation [➙ 27]' and 'Installation [➙ 29]'. 1. Connect the feed line to the terminals in the switching unit (3) or (7), in accordance with the connection diagram. 2.
  • Page 33 Mounting / Installation Installation Figure 14: Installing an auxiliary terminal in housing FDMH293-x Figure 15: Installing manual call points FDM223/FDM224 and FDM223H/FDM224H Seal DMZ1197-AD Cable gripper Screw Housing Switching unit FDME223 Switching unit FDME224 Screw Seal FDMP223 007002_k_en_-- 33 | 54...
  • Page 34: Mounting The Seal Fdmp223

    Mounting / Installation Installation 5.3.1 Mounting the seal FDMP223 The manual call point is electrically connected. 1. Install the seal FDMP223 (1) in the housing FDMH292-R. 2. Check that the seal envelops the sealing lip (2) of the housing. Figure 16: Mounting the seal FDMP223 34 | 54 007002_k_en_--...
  • Page 35: Installing The Protective Cover

    Mounting / Installation Installing the protective cover 5.4 Installing the protective cover If a protective cover (accessories) is used, proceed as follows: A compatible protective cover is available. See the chapter 'Accessories [➙ 22]'. 1. Open the door of the manual call point. 2.
  • Page 36: Installing The Stickers

    2. Insert the stickers so the desired side is displayed. 3. Attach the transparent cover so that it snaps into place at the side. a The manual call point has a new label. Figure 18: Attaching the stickers to a manual call point FDM223 36 | 54 007002_k_en_--...
  • Page 37: Attaching The Window Sign

    Mounting / Installation Attaching the window sign 5.6 Attaching the window sign If you are using housing FDMH292-R, the printed window sign may be covered with a self-adhesive sticker that has been supplied. Observe local regulations for using the self-adhesive sticker! Only use the self- adhesive sticker supplied if local regulations require the manual call point to be labeled in this way.
  • Page 38: Commissioning

    Commissioning Localization and device testing 6 Commissioning The devices are commissioned via the control panel. The exact procedure is described in the control panel documentation. Conduct a performance check once commissioning is complete. 6.1 Localization and device testing The manual call points have an internal alarm indicator. This internal alarm indicator may also be activated from the control panel for localization and device testing.
  • Page 39: Checking Function

    The manual call point is ready for operation again. 10. Set the detector line to 'Normal operation' on the control panel. a The detector line is ready for operation again. Figure 20: Resetting manual call point FDM223 Locking lever 007002_k_en_--...
  • Page 40 Commissioning Checking function Manual call point FDM224 The manual call point is installed and electrically connected. See the chapter 'Installation [➙ 31]'. 1. Set the detector line to 'Test' on the control panel. 2. Push the keyhole cover to the right. 3.
  • Page 41 Commissioning Checking function Manual call point FDM223H The manual call point is installed and electrically connected. See the chapter 'Installation [➙ 31]'. 1. Set the detector line to 'Test' on the control panel. 2. Open the door of the manual call point with the Allen key. 3.
  • Page 42 Commissioning Checking function Manual call point FDM224H The manual call point is installed and electrically connected. See the chapter 'Installation [➙ 31]'. 1. Set the detector line to 'Test' on the control panel. 2. Open the door of the manual call point with the Allen key. The alarm signal is transmitted.
  • Page 43: Maintenance / Repair

    Reset the detector to a state of operational readiness as follows: FDM223 and FDM223H The glass insert has been shattered and the alarm button is pressed. 1. Open the door of the manual call point. See the chapter 'Preparation [➙ 27]'.
  • Page 44: Status Query

    Maintenance / Repair Status query 7.2 Status query Status query on the detector exchanger and tester Each manual call point for FDnet/C-NET features a proximity interface (MC link). Using this interface, it is possible to read out data from the device in a proximity method over short distances with the detector exchanger and tester FDUD292 or the intelligent detector tester FDUD293.
  • Page 45: Replacing The Glass Insert

    Maintenance / Repair Replacing the glass insert 7.4 Replacing the glass insert Manual call points FDM223H and FDM224H The glass insert is square-shaped and can be inserted in any direction. CAUTION Risk of cutting injuries when removing the glass fragments Remove the glass fragments carefully To replace the glass insert, proceed as follows: The door of the manual call point is open.
  • Page 46 Maintenance / Repair Replacing the glass insert Manual call points FDM223H and FDM224H The glass insert is square-shaped and can be inserted in any direction. CAUTION Risk of cutting injuries when removing the glass fragments Remove the glass fragments carefully To replace the glass insert, proceed as follows: The door of the manual call point is open.
  • Page 47: Specifications

    Specifications Technical data 8 Specifications 8.1 Technical data You will find information on approvals, CE marking, and the relevant EU directives for this device (these devices) in the following document(s); see 'Applicable documents' chapter: ● Document 007001 ● Document 008345 Detector line Operating voltage DC 12…33 V...
  • Page 48 50 V/m Mechanical data Design according to EN 54-11: ● FDM223, FDM223H Type B (indirect activation) ● FDM224, FDM224H Type A (direct activation) Housing material: ● FDM223/FDM224 in housing Polycarbonate (PC) FDMH293-x ● FDM223/FDM224 in housing Polycarbonate (PC) FDMH292-R ● FDM223H/FDM224H Polyamide (PA) Housing colors: 48 | 54...
  • Page 49: Dimensions

    Protective cover DMZ1197-AC 0.012 kg ● Sealing for wet areas DMZ1197- 0.022 kg ● Seal FDMP223 for FDM223/224 0.003 kg Standards European standards ● EN 54-11 ● EN 54-17 8.2 Dimensions Manual call points FDM223 and FDM224, housing FDMH293-x 134.3 43.2 007002_k_en_-- 49 | 54...
  • Page 50: Master Gauges For Holes

    Specifications Master gauges for holes Manual call points FDM223 and FDM224, housing FDMH297-R 43.2 Manual call points FDM223H and FDM224H, housing FDMH292-R 134.3 42.5 8.3 Master gauges for holes Manual call points FDM223 and FDM224, housing FDMH293-x 10.65 123.65 116.65 18.15...
  • Page 51: Environmental Compatibility And Disposal

    Specifications Environmental compatibility and disposal Manual call points FDM223 and FDM224, housing FDMH297-R 93.5 17.5 A = Ø 4.5 Manual call points FDM223H and FDM224H, housing FDMH292-R 10.65 123.65 116.65 18.15 A = Ø 4.8 8.4 Environmental compatibility and disposal...
  • Page 52: Index

    Index Index Alarm indicator ........... 19, 38 Impact Application area Chemicals ........... 26 Ambient conditions ........ 26 Moisture ............ 26 Approvals ............ 47 Temperature.......... 26 Installation in wet areas...... 29, 30 Intelligent detector tester FDUD293 CE marking............ 47 MC link .......... 20, 44 Collective behavior Intended use............ 5 Degraded mode operation ...... 21 Interface Compatibility............. 26 MC link ............ 44...
  • Page 53 Index Sealing DMZ1197-AD .......... 32 FDMP223 ............ 34 Short-circuit Line separator .......... 19 Signals transmitted to the control panel Danger levels .......... 19 Spring clips Connections .......... 18 Standards ............ 49 Status query Control panel .......... 44 Surface-mounted cable entry ...... 27 Test mode Manual call point ......... 19 Type plate Product version ........... 15 007002_k_en_--...
  • Page 54 © Siemens Switzerland Ltd, 2004 Issued by Siemens Switzerland Ltd Technical specifications and availability subject to change without notice. Smart Infrastructure Global Headquarters Theilerstrasse 1a CH-6300 Zug +41 58 724 2424 www.siemens.com/buildingtechnologies 007002_k_en_--...
