SIP User's Manual
9.6.2.5
Fax / Modem Transparent with Events Mode
In this mode, fax and modem signals are transferred using the current voice coder with the
following automatic adaptations:
Echo Canceller = on (or off, for modems)
Echo Canceller Non-Linear Processor Mode = off
Jitter buffering optimizations
To configure fax / modem transparent with events mode, perform the following
configurations:
IsFaxUsed = 0
FaxTransportMode = 3
V21ModemTransportType = 3
V22ModemTransportType = 3
V23ModemTransportType = 3
V32ModemTransportType = 3
V34ModemTransportType = 3
BellModemTransportType = 3
9.6.2.6
G.711 Fax / Modem Transport Mode
In this mode, when the terminating device detects fax or modem signals (CED or AnsAM), it
sends a Re-INVITE message to the originating device requesting it to re-open the channel
in G.711 VBD with the following adaptations:
Echo Canceller = off
Silence Compression = off
Echo Canceller Non-Linear Processor Mode = off
Dynamic Jitter Buffer Minimum Delay = 40
Dynamic Jitter Buffer Optimization Factor = 13
After a few seconds upon detection of fax V.21 preamble or super G3 fax signals, the
device sends a second Re-INVITE enabling the echo canceller (the echo canceller is
disabled only on modem transmission).
A 'gpmd' attribute is added to the SDP according to the following format:
For G.711A-law: a=gpmd:0 vbd=yes;ecan=on (or off, for modems)
For G.711 µ-law: a=gpmd:8 vbd=yes;ecan=on (or off for modems)
The parameters FaxTransportMode and VxxModemTransportType are ignored and
automatically set to the mode called 'transparent with events'.
To configure fax / modem transparent mode, set IsFaxUsed to 2.
Version 5.8
497
9. IP Telephony Capabilities
October 2009
