1.3 Supported Software

1.3.1 Programming Library

Windows NT/2000/XP DLL are provided for the cPCI-8168 users.
These function libraries are shipped with the board.

1.3.2 MotionCreator

This Windows-based utility is used to setup cards, motors, and
systems. It can also aid in debugging hardware and software prob-
lems. It allows users to set I/O logic parameters to be loaded in
their own program. This product is also bundled with the card.
Refer to Chapter 5 for more details.

1.4 Available Terminal Board

DIN-68S/2, DIN-68Y-SGII, DIN-68P-A4 and DIN-68M-J3A are
available for cPCI-8168 wiring. DIN-68S/2 is general purposed
pin-to-pin terminal board. Users can use this to connect servos
and steppers. DIN-68M-J3A is designed for Mitsubishi servo J3A
amplifer.DIN-68Y-SGII is designed for Yaskawa SigmaII amplifer.
DIN-68P-A4 is designed for Panasonic Minax A4 amplifer. Users
can use these boards to connect servo driver and steppers.
