CmpMethod =4, CmpValue>Counter
CmpMethod =5, CmpValue<Counter
CmpAction: The reacting mode when comparison comes into
exist
CmpAction =0, INT only
CmpAction =1, Immediately stop
CmpAction =2, slow down then stop
CmpAction =3, speed change
Data: Comparing value,
cmp_sts: status of comparator
Bit
0 +Softlimit On
1 -SoftLimit On
2 Error counter comparator On
3 General comparator On
4 Trigger comparator On (for 0 , 1 axis only)
SelectSrc: The comparing data source
SelectSrc =0, disable auto compare
SelectSrc =1, use FIFO as compare data storage
Start: Start point of compare function
End: End point of compare function
Interval: Interval of compare function
TableArray: Array of comparing data
Size: Size of table array
Device: Selection of reload device for comparator data
Device =0, Useless
Device =1, use FIFO as compare data storage
Res_dist: The remain distance from the compare point. After
comparison, the original target position will be ignored, and the
axis will keep moving the Res_dist.
