General-Purpose Digital Output
8 channels isolated level Digital Output: DOUT
Output voltage range: 5V - 35V
Output type: NPN open collector
Darlington transistor array: TD62083
Sink current: 90 mA Max each channel
8 channels isolated level Digital Input: DIN
Input voltage range: 0V - 30V
Input resistor 4.7Kohm (1/2W)
Isolation optocoupler: PC3H4
4 channels high speed digital input: HSIN
Input voltage range: 0 - 5V
Change of State detection
Isolation optocoupler: HP0631
4 channels high speed digital output with high current output
ability: HSOUT
Output voltage range: 5V - 30V
Output type: Open Drain Power MOS
Sink current: 1Amp. Max each channel
Signal switching time: Maximum 15 ns.
Analog Input: AIN
Converter and Resolution:
12 Bit Linear Technology LTC1402
Input channels: 4 Single-Ended
Input range: +/- 10V; Bipolar
Conversion Time: 5u sec
Sampling rate:200K samples/sec maximum
Output Voltage: Min. 5V; Max.35V
Over voltage protection: Continuous +/-35V
Accuracy: 0.01% of FSR +/-1 LSB
6
Introduction
