ADLINK Technology cPCI-3534 User Manual

4/8 ports serial communication modules
Hide thumbs Also See for cPCI-3534:

Advertisement

Quick Links

Download this manual
cPCI-3534/3544/3538 &
cPCI-3534R/3544R/3538R
4/8 Ports Serial
Communication Modules
User's Guide
Recycled Paper
This datasheet has been downloaded from
http://www.digchip.com
at this
page

Advertisement

loading
Need help?

Need help?

Do you have a question about the cPCI-3534 and is the answer not in the manual?

Questions and answers

Related Manuals for ADLINK Technology cPCI-3534

Summary of Contents for ADLINK Technology cPCI-3534

  • Page 1 & cPCI-3534R/3544R/3538R 4/8 Ports Serial Communication Modules User’s Guide Recycled Paper This datasheet has been downloaded from http://www.digchip.com at this page...
  • Page 2 Trademarks cPCI-3534, cPCI-3544 and cPCI-3538 are registered trademarks of ADLINK TECHNOLOGY INC., MS-DOS, Windows 95, and Windows NT are registered trademark of Microsoft Corporation. Intel® is a registered trademark of Intel Corporation.
  • Page 3 Getting Service from ADLINK Customer Satisfaction is top priority for ADLINK Technology Inc. If you need any help or service, please contact us. ADLINK TECHNOLOGY INC. Web Site http://www.adlinktech.com Sales & Service Service@adlinktech.com +886-2-82265877 +886-2-82265717 Address 9F, No. 166, Jian Yi Road, Chungho City, Taipei, 235 Taiwan Please email or FAX your detailed information for prompt, satisfactory, and consistent service.
  • Page 4 ADLINK cPCI Multi-port Communication Module Comparison Chart Type cPCI-3534 cPCI-3544 cPCI-3538 cPCI-3534R cPCI-3544R cPCI-3538R Serial port 4~32 8~16 4~32 8~16 per system RS-232 port per module RS-422/485 per module Serial communicati 16C554 16C554 16C554 16C554 16C554 16C554 on controller MAX System 115.2K*4...

  • Page 5: Table Of Contents

    Table of Contents Introduction.................1 cPCI-3534 Overview ..............1 cPCI-3544 Overview ..............7 cPCI-3538 Overview .............. 13 Installation.................19 What You Have ..............19 Unpacking ................20 Installation Procedure............. 21 Hardware Configuration ............22 Software Installation ............... 23 AP Examples................31 Table of Contents •...

  • Page 7: Introduction

    1.1 cPCI-3534 Overview 1.1.1 What is the cPCI-3534? The cPCI-3534 is an enhanced four ports serial communication module used for Compact-PCI platform. It includes a PGA (Programmable Gate Array) to support the serial communication controller and a 37-pin connector to connect external I/O port from the front panel or using the rear The expansion cable has four standard DB25 or DB9 connectors and one DB37 connector to connect with cPCI-3534 interface card.
  • Page 8 1.1.3 cPCI-3534 Specifications • Compliant with PCI Spec.2.1 • Serial communication controller: 16C550A compatible 1.8432 - 7.3728MHz • System I/O mapping: Assigned by PCI BIOS Shared IRQ • Flow control Xon/Xoff control RTS/CTS control (Only for RS-232 Interface) • Port Capability:...
  • Page 9 J2 connector DIP SWITCH DB37 female connector cPCI-3534R cPCI-3534R Profile 1.1.4 cPCI-3534 Connector Pin Assignment DB37 female connector pin assignment for the cPCI-3534. RS-232 Interface RS-422 Interface 4S-485 Interface Pin No. (Port A, B, C) (Port D) (Port D) PortA_RXD(IN)
  • Page 10 PortB_RI(IN) PortC_RI(IN) PortC_DCD(IN) PortC_DSR(IN) PortC_CTS(IN) PortC_RXD(IN) PortD_TXD-(OUT) PortD_TXD+(OUT) DB25 male connector pin assignment in the cPCI-3534 module for RS-232 interfaces (port A, B, and C) and the RS-422/485 interface (port D). RS-422 RS-232 Interface RS-485 Interface Interface TXD(OUT) TXD+(OUT) RXD(IN)
  • Page 11 Pin No. RS-232 Interface RS-422 Interface RS-485 Interface DCD(IN) RXD(IN) RXD+(IN) TXD(OUT) TXD+(OUT) DTR (OUT) TXD-(OUT) Isolated GND DSR(IN) RXD-(IN) RTS(OUT) CTS(IN) RI(IN) Compact PCI J2 connector pin assignment in cPCI-3534R module for RS-232/422/485 interfaces (cPCI-3534R only). TXD+ TXD- RXD+ RXD- GND DSR GND DSR...
  • Page 12 RS-232 FG : Frame Ground Transmit Data RX : Receive Data RTS : Request to Send Clear to Send DSR : Data Set Ready SG : Signal Ground Data Carrier Detect DTR : Data Terminal Ready RS-422 TXD+ Transmit Data Positive TXD- Transmit Data Negative RXD+...

  • Page 13: Cpci-3544 Overview

    1.2 cPCI-3544 Overview 1.2.1 What is the cPCI-3544? The cPCI-3544 is an enhanced four ports serial communication module for industry communication interface RS-422/485 by Compact-PCI platform. It includes a PGA (Programmable Gate Array) to support the serial communication controller and a 37-pin connector to connect external I/O port from the front panel or using the rear I/O.
  • Page 14 • Port Capability: Four isolated RS-422/485 port (DIP switch select) Max. port per system: 32 (8 card) • Isolation voltage: 500VDC • Baud rate: Each port can be configured to 50 - 115,200 bps • Operation System Compatibility: Windows 95/98/NT/QNX •...
  • Page 15 1.2.4 Connector Pin Assignment of cPCI-3544 DB37 female connector pin assignment for cPCI-3544. Pin No. RS-422 Interface 4S-485 Interface PortA_RXD+(IN) PortA_D+(I/O) PortA_RXD-(IN) PortA_D-(I/O) PortA_ IsolatedGND PortB_TXD+(OUT) PortB_TXD-(OUT) PortB_ Isolated GND PortC_Isolated GND PortC_TXD-(OUT) PortC_TXD+(OUT) PortD_Isolated GND PortD_D-(I/O) PortD_RXD-(IN) PortD_D+(I/O) PortD_RXD+(IN) PortA_TXD+(OUT) PortA_TXD-(OUT) PortB_RXD+(IN)
  • Page 16 DB25 male connector pin assignment in cPCI-3544 module for RS-422/485 interface. (Port A - D) Pin No. RS-422 Interface RS-485 Interface TXD+ RXD+ RXD- Each Port Isolated GND TXD- DB9 male connector pin assignment in cPCI-3544 module for RS-422/485 interface. (Port A - D) Pin No.
  • Page 17 Compact PCI J2 connector pin assignment in cPCI-3544R module for RS-422/485 interface. (cPCI-3544R only) TXD- TXD+ GND GND RXD- RXD+ TXD- TXD+ GND GND RXD- RXD+ TXD- TXD+ GND GND RXD- RXD+ TXD- TXD+ GND GND RXD- RXD+ Port A Port B Port C Port D...
  • Page 18 cPCi-R3544 Rear I/O Daughter Board (Rear I/O function only for cPCI-3544R) The cPCi-R3544 rear I/O daughter board provides a rear I/O connection transition, the connector and cable used in the rear is the same as the front. DIP Switch and Jumper Setting CARD NO.

  • Page 19: Cpci-3538 Overview

    cPCI-3538 Overview 1.3.1 What is the cPCI-3538? The cPCI-3538 is an enhanced eight ports serial communication card used for cPCI platform. It includes a PGA (Programmable Gate Array), which supports the serial communication controller, and a 62-pin connector which connects external I/O port on the front panel or the rear I/O. The expansion cable has eight standard DB25 connectors and one DB62 connector to connect to cPCI-3538 interface card.
  • Page 20 1.3.3 Specification of cPCI-3538 • Compliant with PCI Spec.2.1 • Serial communication controller: 16C550A compatible 1.8432 - 7.3728 MHz • System I/O mapping: Assigned by PCI BIOS Shared IRQ • Flow control Xon/Xoff control RTS/CTS control • Port Capability: Eight independent RS-232C compatible ports Optional external C588XB box for extending to eight isolated RS-232/422/485 port Max.
  • Page 21 J2 connector DB62 female connector cPCI-3538R cPCI-3538R Profile Introduction • 15...
  • Page 22 1.3.4 Connector Pin Assignment of cPCI-3538 DB62 female connector pin assignment for cPCI-3538. Pin No. Signal Name Pin No. Signal Name PortA_TXD (OUT) PortG_CTS(IN) PortA_RXD (IN) PortG_DSR(IN) PortA_RTS (OUT) PortG_DTR(OUT) PortA_CTS (IN) PortG_DCD(IN) PortA_DSR (IN) PortF_TXD(OUT) PortA_DTR (OUT) PortF_RXD(IN) PortA_DCD (IN) PortF_RTS(OUT) PortC_TXD(OUT) PortF_CTS(IN)
  • Page 23 CTS(IN) DSR(IN) DCD(IN) DTR(OUT) DB9 male connector pin assignment in the cPCI-3538 module for RS-232 interfaces (port A - H). Pin No. Signal Name DCD(IN) RXD(IN) TXD(OUT) DTR (OUT) DSR(IN) RTS(OUT) CTS(IN) Introduction • 17...
  • Page 24 Compact PCI J2 connector pin assignment in cPCI-3538R module for RS-232 interface. (cPCI-3538R only) RS-232 Frame Ground Transmit Data Receive Data Request to Send Clear to Send Data Set Ready Signal Ground Data Carrier Detect Data Terminal Ready cPCI-R3538 Rear I/O Daughter Board (Rear I/O function only for cPCI-3538R) The cPCI-R3538 rear I/O daughter board provides a rear I/O connection transition;...

  • Page 25: Installation

    2.1 What You Have In addition to this User's Manual, the package includes the following items: • cPCI-3534/3544/3538 Serial Communication Interface Module • Expansion Cable (C425M, C409M or C825M, C809M) • R-3534/3538 Rear I/O Daughter Board (For the rear I/O version) •...

  • Page 26: Unpacking

    2.2 Unpacking Your serial communication module contains sensitive electronic components that can be easily damaged by static electricity. The module should be done on a grounded anti-static mat. The operator should be wearing an anti-static wristband, grounded at the same point as the anti-static mat.

  • Page 27: Installation Procedure

    2.3 Installation Procedure Turn off your cPCI computer system. Turn off all accessories (printer, modem, monitor, etc.) connected to computer. Select a cPCI slot. Before handling the serial communication module, discharge any static buildup on your body by touching the metal case of the computer.

  • Page 28: Hardware Configuration

    BIOS. The address assignment is done on a board-by-board basis for all serial communication cards in the system. The jumper SW1-1 for cPCI-3534 and the JP1 for cPCI-3538 is used for the system to recognize the first or second card of the same model in the system if there are two of the same cards on the board.

  • Page 29: Software Installation

    Go to the end of this list and select <Other> requires disk from manufacturer. When prompted for the path, specify the drive and directory where the NCPA can find the new driver for the card installed. For cPCI-3534, specify as follows: X:\NuCOM\CPCI3534\NT4 For cPCI-3544, specify as follows: X:\NuCOM\CPCI3544\NT4...
  • Page 30 When two of the same type of serial communication cards are required to be installed in one NT system, confirm to let one card’s SW1-1 is ON while the other card’s SW1-1 is OFF for cPCI-3534 and JP1 is ON while the other card’s JP1 is OFF for cPCI-3538.
  • Page 31 The driver does not need to be installed again, Windows 95/98 will add the COM port automatically. You can install up to two cPCI-3534/3538 cards on one 95/98 system. When two of the same type of cards are required to be installed on one 95/98 system, confirm to let one card’s switch to be ON, and...
  • Page 32 As the resource will be assigned by PCI BIOS, it is relatively difficult to check which card is first card or second card from resource. For this reason, ADLINK has placed a jumper in each cPCI-3534/3538 card to set the first card or second card for this these comport cards. (cPCI-3544 does not include this function).
  • Page 33 have a different directory name. Please link to /usr/src/linux name. Installation for cPCI-3544 Linux Driver 1. UNPACK Decompress the pci3544.tgz (pci3544.tgz is located in “X:\SerialComm \cPCI-3544 \Linux” directory; X is the CD-ROM.)) : tar xvzf pci3544.tgz This will extract the 'cPCI_3544' directory in the Linux. There are two subdirectories as follows: drivers/ contains the device module and the installation script util/...
  • Page 34 or simply execute the following command if the device module is in the current directory. ./3544_inst.pl -cards 3 The optional parameter '-path' is used to indicate the directory of pci-3544package. If the cPCI-3544 driver can not be found in working directory, the optional parameter '-path' is required. ./3544_inst.pl -cards 2 -path /usr/local/pci_3544 After installing the devices successfully, the ports of cPCI-3544 can be used as the normal serial ports supported by Linux.
  • Page 35 2.5.5 Windows 95/98/NT Utility Diagram for cPCI-3544 The cPCI-3534/3538 does not require any configuration utility. It is similar to the system COM ports. The cPCI-3544 is a 4-Port RS-422/485 serial communication module. It supports the software configuration for RS-422/485. When choosing the RS-422 mode, the RS-485 port would be disabled automatically.
  • Page 36 Existing Cards and its port distribution The first one port maps to system port. Port mode When checked, the configuration will be true after rebooting. If it is not checked, after rebooting, the port mode will follow the DIP switch configuration. 30 •...

  • Page 37: Ap Examples

    Follow the installation guide above first. 2.6.1 Dos Environment For cPCI-3534/3538, please refer to the README file included in the driver. The cPCI-3544 does not provide the DOS library. If the user wishes to program by themselves, contact the dealer from whom the product was purchased, or the service mailbox in ADLINK.

  • Page 38: Warranty Policy

    Warranty Policy Thank you for choosing ADLINK. To understand your rights and enjoy all the after-sales services we offer, please read the following carefully. 1. Before using ADLINK’s products please read the user manual and follow the instructions exactly. When sending in damaged products for repair, please attach an RMA application form which can be downloaded from: http://rma.adlinktech.com/policy/.
  • Page 39 • Damage caused by carelessness on the user's part during product transportation. • Damage caused by fire, earthquakes, floods, lightening, pollution, other acts of God, and/or incorrect usage of voltage transformers. • Damage caused by inappropriate storage environments such as with high temperatures, high humidity, or volatile chemicals.

This manual is also suitable for:

Cpci-3544Cpci-3538Cpci-3534rCpci-3544rCpci-3538r
