download location on your PC. To change the name of a Customer
EDID, type the new name in the space provided, then click on the
"Save Name" button.
• Sink EDID Download
To save the EDID from one of the connected displays to your local
PC, select the appropriate sink from the dropdown list then press the
"Download" button. Depending on your browser settings you will
either be asked where to save the downloaded file, or the file will be
transferred to the default download location on your PC.
• Set EDID Input Content
The Set EDID Input Content section provides controls for assigning EDID
to the matrix's inputs. Selecting "Appoint" allows for different EDID
to be assigned to each individual input, selecting "ALL" allows for a
single EDID to be assigned to all inputs.
• EDID Source
Click on the preferred input(s) to open the EDID Source management
window. Multiple inputs can be selected at once, if desired. Select the
new EDID source to use and the change will occur immediately.
Note: In most cases, assigning a new EDID to an input will cause the
affected input to briefly blink out while the source adapts to the new
information.
• Unit's Default EDIDs
This matrix provides the following 6 default EDIDs:
FHD/2CH
FHD/MCH
UHD/2CH
UHD/MCH
UHD+/2CH
UHD+/MCH
29
1920×1080p@60Hz (148MHz),
8-bit color
1920×1080p@60Hz (148MHz),
8-bit color
3840×2160p@30Hz (297MHz), Deep
Color (8/10/12-bit)
3840×2160p@30Hz (297MHz), Deep
Color (8/10/12-bit)
3840×2160p@60Hz (594MHz), Deep
Color (8/10/12-bit)
3840×2160p@60Hz (594MHz), Deep
Color (8/10/12-bit)
LPCM 2.0
LPCM 7.1 &
Bitstream
LPCM 2.0
LPCM 7.1 &
Bitstream
LPCM 2.0
LPCM 7.1 &
Bitstream
