CYP CPLUS-V8H8HP Operation Manual page 25

6.8.5 HDCP Commands
COMMAND
DESCRIPTION
GET OUT N1 HDCP ABILITY
Show the HDCP capability
detected from the display
connected to output N1.
6.8.6 Ethernet Commands
COMMAND
DESCRIPTION
SET IP MODE N1
Set the IP address assignment
mode.
GET IP MODE
Show the current IP mode.
GET IPCONFIG
Show the current complete IP
configuration.
SET IPADDR N1
Set the static IP address.
GET IPADDR
Show the current static IP address.
SET NETMASK N1
Set the netmask address.
GET NETMASK
Show the current netmask.
SET GATEWAY N1
Set the gateway address.
VARIABLES
N1 = A ~ H
[Output Port]
Available result codes:
0 [No HDCP]
1 [HDCP 1.x]
2 [HDCP 2.2]
VARIABLES
Available values for N1:
0 [Static IP Mode]
1 [DHCP Mode]
N1 = X.X.X.X
[X = 0 ~ 255]
N1 = X.X.X.X
[X = 0 ~ 255]
N1 = X.X.X.X
[X = 0 ~ 255]
20
