6.5 IR Cable Pin Assignments

IR Extender

6.6 RS-232 Protocol

UNIT
Pin Pinout
1
2 TxD
3 RxD
4
5 GND
6
7
8
9
7
LEVEL 2
Mode Static
Mode DHCP
TERMINAL
Pin Pinout
1
2 RxD
3 TxD
4
5 GND
6
7
8
9
LEVEL 3
IP:
Mask:
Gate:
[Info Display]
Infrared
1
Power
2
3
Ground
SERIAL PORT SETTINGS
Baud Rate
Data Bits
Parity Bits
Stop Bits
Flow Control
LEVEL 4
19200
8
None
1
None
