Procedure
Select the RTK Network correction signal
1.
under 'Signal Type'.
Select the modem type "External modem"
2.
Enter the baud rate
3.
Select parity
4.
Select signal format
5.
Display
Satellite receiver
Signal type
Modem type
Signal strength
Accuracy
Signal lag
Connection status
Authorisation level
Baud rate
Parity
Signal format
VarioGuide
438.020.070.012
Designation of the installed receiver
The correction signal source can be selected here
External modem
Mobile communications signal strength
Bar indicator and decimal value of static accuracy
Specifies the time in s taken to receive the correction signal update. If 999 is
shown here, the correction signal cannot be currently received.
Specifies the connection status of the GNSS receiver to the source of the
correction data (e.g. connected, update required, expired). The tick shows
whether the GNSS receiver is currently connected to the correction data
source.
Specifies the accuracy level of the GNSS receiver (depending on the hardware
modules installed in the receiver)
9600 / 19200 / 38400 / 57600 / 115200
Invalid/none/even/odd
CMR/RTCM 2.3/RTCM 3.1
Fig. 47
7. Start-up
