7. Start-up
Display
Signal lag
Connection status
Authorisation level
Signal format

7.10.3 RTK network (external mobile radio modem)

7.10.3.1 Configure the external mobile modem correction signal

NOTE:
After the ignition has been switched OFF/ON, the system connects to the GSM/GPRS network
automatically and without further notice, provided that a connection was established before the ignition
was switched off. Please note that this action may result in data charges.
Procedure
Select the RTK Network correction signal
1.
under 'Signal Type'.
Select the modem type "External modem"
2.
Enter the baud rate
3.
Select parity
4.
Select signal format
5.
108
Specifies the time in s taken to receive the correction signal update. If 999 is
shown here, the correction signal cannot be currently received.
Specifies the connection status of the GNSS receiver to the source of the
correction data (e.g. connected, update required, expired). The tick shows
whether the GNSS receiver is currently connected to the correction data
source.
Specifies the accuracy level of the GNSS receiver (depending on the hardware
modules installed in the receiver)
w
Fig. 56
