Select the trailer type.
3.
Assign a name and press
4.
7.2.4.2 Determine the working width, navigation point distance and coupling length
Working width
Actual working width of
the implement
VarioGuide
438.020.070.012
to confirm.
Center
Movement of the
implement from the
center (e.g. for mowers)
Heckgeräteanbauposition auswählen
Heckkraftheber
Gezogenes Gerät
Fig. 19
Fig. 20
Navigation point
Distance of the
horizontal rotational axis
of the implement from
the lower link hooks
7. Start-up
Coupling length
Distance of the
processing area of the
implement from the
lower link hooks
77
