Egnos / Waas - FENDT varioguide Operator's Manual

7. Start-up

7.6.2 EGNOS / WAAS

Set correction signal
Select the correction signal via the "Signal
Type" selection field.
Display
Satellite receiver
Signal type
Accuracy
Signal lag
Connection status
Authorisation level
92
Designation of the installed receiver
The correction signal source can be selected here
Bar indicator and decimal value of static accuracy
Specifies the time in s taken to receive the correction signal update. If 999 is
shown here, the correction signal cannot be currently received.
Specifies the connection status of the GNSS receiver to the source of the
correction data (e.g. connected, update required, expired). The tick shows
whether the GNSS receiver is currently connected to the correction data
source.
Specifies the accuracy level of the GNSS receiver (depending on the hardware
modules installed in the receiver)
Fig. 40
VarioGuide
438.020.070.012
