7. Start-up

7.4 Exchange implement data and field data

7.4.1 Plug in the USB stick and call up data exchange

Implement data and field data can be transferred from tractor to tractor using a USB stick (when using
VarioGuide).
The USB stick can also be used to back up the implement data and field data, e.g. before replacing the
terminal.

7.4.1.1 Insert USB stick

Procedure
Pull flap (A) open to reveal the USB ports.
1.
Insert USB stick into the appropriate port.
2.

7.4.1.2 Call up data exchange on 10.4"

1
24 10 2011
11 10 10 35
Fig. 30
Press the "Management main menu" soft key on the "Management info" page, the "Management
1.
main menu" page is displayed
On the "Management main menu" page, press the soft key for the data exchange; the "Data
2.
exchange" page is displayed.
84
Fig. 29
2 3
VarioGuide
438.020.070.012
