IMB760 LGA4189 EATX Motherboard
2.5

Connectors

Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, Make sure all connectors are properly and firmly connected. Here is a
summary table showing the connectors on the hardware.
Connector
VGA1
CN2
CN1
LAN1
LAN2
CN11
CN7
CN10
U1
U2
CN18
ATX1
CN16
CN17
CN12
CN13
ATX2
PMBUS1
CN15
COM1
FAN1~6
CPUFAN1
CPUFAN2
USB1
USB2
USB3
USB4
Slot2, Slot7
Slot3, Slot4, Slot5, Slot6
SATA1~SATA4
CN3
CN4
IPMICOM1
CN5
JP26, JP27
JP28
P1-DIMMA~P1-DIMMH
P2-DIMMA~P2-DIMMH
10
Description
VGA Connector
LAN (Shared IPMI LAN) + USB3.1 GEN1 Connector
USB3.1 GEN1 Connector
10G LAN Connector
10G LAN Connector
TPM 2.0 Connector (Optional)
M.2 Connector
M.2 Connector
CPU1 Socket
CPU2 Socket
Front Panel Header
24-pin ATX Power Input Connector
CPU1 Power Input Connector
CPU1 AUX Power Input Connector
CPU2 Power Input Connector
CPU2 AUX Power Input Connector
CPU2 ATX 12V Power Input Connector
PMBUS Connector
Internal USB3.1 GEN1 Connector
COM port Connector
System Fan Connectors
CPU1 Fan Connector
CPU2 Fan Connector
Internal USB2.0 Type A Connector
Internal USB2.0 Type A Connector
Internal USB2.0 Headers
Internal USB2.0 Headers
PCI-Express x8 Slots (Gen4)
PCI-Express x16 Slots (Gen4)
SATA III Connector
Internal PS2 Key Board Connector
Internal PS2 Mouse Connector
Internal IPMI COM Connector
Internal DIO Connector
LAN Active LED connectors
Programmable LED connectors
CPU1 DDR4 RDIMM Connector
CPU1 DDR4 RDIMM Connector
