The warning functions are activated when the output
frequency has reached the selected reference.
The signal outputs can be programmed to
generate a warning signal via terminal 42 or
45 and via the relay outputs.
Description of choice:
The lower signal limit of the motor frequency, f
must be programmed within the normal working
range of the frequency converter. See drawing at
parameter 221Warning: Low current, I
224 Warning: High frequency , f
(WARN. HIGH FREQ.)
Value:
Par. 200 Output frequency range = 0-120 Hz [0].
parameter 223 - 120 Hz
Par. 200 Output frequency range = 0-1000 Hz [1].
parameter 223 - 1000 Hz
Function:
If the output frequency is above the limit, f
programmed in this parameter, the display will
show a flashing FREQUENCY HIGH.
The warning functions in parameters 221-228 are
not active during ramp-up after a start command,
ramp-down after a stop command or while stopped.
The warning functions are activated when the output
frequency has reached the resulting reference.
The signal outputs can be programmed to
generate a warning signal via terminal 42 or
45 and via the relay outputs.
Description of choice:
The higher signal limit of the motor frequency, f
must be programmed within the normal working
range of the frequency converter. See drawing at
pa-rameter 221 Warning: Low current, I
225 Warning: Low reference, REF
(WARN. LOW REF.)
Value:
-999,999.999 - REF
HIGH
Function:
When the remote reference lies under the limit,
Ref , programmed in this parameter, the display
LOW
shows a flashing REFERENCE LOW.
The warning functions in parameters 221-228 are
not active during ramp-up after a start command,
ramp-down after a stop command or while
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.61.A5.02 - VLT is a registered Danfoss trademark
,
LOW
.
LOW
HIGH
120.0 Hz
120.0 Hz
,
HIGH
,
HIGH
.
LOW
LOW
(par.226)
-999,999.999
®
VLT 6000 HVAC Series
stopped. The warning functions are activated when
the output frequency has reached the selected
reference. The signal outputs can be programmed
to generate a warning signal via terminal 42 or
45 and via the relay outputs.
The reference limits in parameter 226 Warning:
High reference, Ref , and in parameter 225
HIGH
Warning: Low reference, Ref
when remote reference has been selected.
In Open loop mode the unit for the reference is Hz,
while in Closed loop mode the unit is programmed
in parameter 415 Process units.
Description of choice:
The lower signal limit, Ref
LOW
be programmed within the normal working range of
the frequency converter, provided parameter 100
Configuration has been programmed for Open loop
[0]. In Closed loop [1] (parameter 100), Ref
must be within the reference range programmed
in parameters 204 and 205.
226 Warning: High reference , REF
(WARN. HIGH REF.)
Value:
REF (par. 225) - 999,999.999
Low
Function:
If the resulting reference is above the limit, Ref
programmed in this parameter, the display shows
a flashing REFERENCE HIGH.
The warning functions in parameters 221-228 are
not active during ramp-up after a start command,
ramp-down after a stop command or while stopped.
The warning functions are activated when the output
frequency has reached the resulting reference.
The signal outputs can be programmed to
generate a warning signal via terminal 42 or
45 and via the relay outputs.
The reference limits in parameter 226 Warning:
High reference, Ref , and in parameter 227
HIGH
Warning: Low reference, Ref
when remote reference has been selected.
In Open loop the unit for the reference is Hz,
while in Closed loop the unit is programmed in
parameter 415 Process units .
Description of choice:
The upper signal limit, Ref
HIGH
be programmed within the normal working range of
the frequency converter, provided parameter 100
Configuration has been programmed for Open loop
, are only active
LOW
, of the reference must
LOW
HIGH
999,999.999
,
HIGH
, are only active
LOW
, of the reference must
