Description of choice:
See data choice and connections in Relay outputs.
324 Relay 01, ON delay
(RELAY1 ON DELAY)
Value:
0 - 600 sec.
Function:
This parameter allows a delay of the cut-in time
of relay 1 (terminals 1-2).
Description of choice:
Enter the desired value.
325 Relay 01, OFF delay
(RELAY1 OFF DELAY)
Value:
0 - 600 sec.
Function:
This parameter makes it possible to delay the
cut-out time of relay 01 (terminals 1-2).
Description of choice:
Enter the desired value.
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.61.A5.02 - VLT is a registered Danfoss trademark
®
VLT
326 Relay 2, output function
(RELAY2 FUNCTION)
Value:
See functions of relay 2 on previous page.
Function:
This output activates a relay switch. Relay switch
0 sec.
2 can be used for indicating status and warnings.
The relay is activated when the conditions for the
relevant data values have been fulfilled.
See General technical data.
Description of choice:
See data choice and connections in Relay outputs.
327 Pulse reference, max. frequency
(PULSE REF. MAX)
Value:
100 - 65000 Hz at terminal 29
0 sec.
100 - 5000 Hz at terminal 17
Function:
This parameter is used to set the pulse value that must
correspond to the maximum reference, parameter
205 Maximum reference, Ref
The pulse reference signal can be connected
via terminal 17 or 29.
Description of choice:
Set the required maximum pulse reference.
328 Pulse feedback, max. frequency
(PULSE FDBK MAX.)
Value:
100 - 65000 Hz at terminal 33
Function:
This is where the pulse value that must correspond
to the maximum feedback value is set. The pulse
fedback signal is connected via terminal 33.
Description of choice:
Set the desired feedback value.
6000 HVAC Series
.
MAX
5000 Hz
25000 Hz
113
