Danfoss VLT 6000 series Operating Instructions Manual page 87

37 kW (37.00 KW)
45 kW (45.00 KW)
55 kW (55.00 KW)
75 kW (75.00 KW)
90 kW (90.00 KW)
110 kW] (110.00 KW)
132 kW (132.00 KW)
160 kW (160.00 KW)
200 kW (200.00 KW)
250 kW (250.00 KW)
300 kW (300.00 KW)
315 kW (315.00 KW)
355 kW (355.00 KW)
400 kW (400.00 KW)
450 kW (450.00 KW)
500 kW (500.00 KW)
550 kW (550.00 KW)
Depends on the unit
Function:
This is where to select the kW value P
corresponds to the rated power of the motor. At the
works, a rated kW value P
that depends on the type of unit.
Description of choice:
Select a value that equals the nameplate data on the
motor. There are 4 possible undersizes or 1 oversize in
comparison with the factory setting. Also, alternatively
it is possible to set the value for motor power as an
infinitely variable value, see the procedure for Infinitely
variable change of numeric data value .
103 Motor voltage, U
M,N
(MOTOR VOLTAGE)
Value:
200 V
208 V
220 V
230 V
240 V
380 V
400 V
415 V
440 V
460 V
480 V
500 V
550 V
575 V
600 V
Depends on the unit
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.61.A5.02 - VLT is a registered Danfoss trademark
[3700]
[4500]
[5500]
[7500]
[9000]
[11000]
[13200]
[16000]
[20000]
[25000]
[30000]
[31500]
[35500]
[40000]
[45000]
[50000]
[55000]
that
M,N
has been selected
M,N
[200]
[208]
[220]
[230]
[240]
[380]
[400]
[415]
[440]
[460]
[480]
[500]
[550]
[575]
[600]
®
VLT 6000 HVAC Series
Function:
This is where the rated motor voltage U
set for either star Y or delta
Description of choice:
Select a value that equals the nameplate data on
the motor, regardless of the mains voltage of the
frequency converter. Furthermore, alternatively it is
possible to set the value of the motor voltage infinitely
variably. Also refer to the procedure for infinitely
variable change of numeric data value.
NB!:
Changing parameters 102, 103 or 104 will
automatically reset parameters 105 and 106
to default values. If changes are made to
parameters 102, 103 or 104, go back and reset
parameters 105 and 106 to correct values.
104 Motor frequency, f
(MOTOR FREQUENCY)
Value:
50 Hz (50 HZ)
60 Hz (60 HZ)
Function:
This is where the rated motor frequency f
Description of choice:
Select a value that equals the nameplate data
on the motor. Furthermore, it is also possible
to set the value for motor frequency infinitely
variably in the 24-1000 Hz range.
105 Motor current, I
M,N
(MOTOR CURRENT)
Value:
0.01 - I A
VLT,MAX
Function:
The rated motor current I
M,N
converter calculations i.a. of torque and motor thermal
protection. Set the motor current I
account the star Y or delta connected motor.
Description of choice:
Set a value that equals the nameplate data on the motor.
is
M,N
.
M,N
[50]
[60]
is selected.
M,N
(MOTOR CURRENT)
Depends on the unit
forms part of the frequency
, taking into
VLT,N
87
