Function:
Select the function which is to be activated
when the frequency converter is exposed to
an overtemperature condition.
Description of choice:
At Trip [0] the frequency converter will stop the
motor and export an alarm.
At Autoderate & warning [1] the frequency converter will
first reduce the switching frequency to minimize internal
losses. If the overtemperature condition persists, the
frequency converter will reduce the output current
until the heat sink temperature stabilizes. When the
function is active, a warning will be exported.
412 Trip delay overcurrent, I
(OVERLOAD DELAY)
Value:
0 - 60 sec. (61=OFF) .
Function:
When the frequency converter registers that the output
current has reached the current limit I
215 Current limit) and stays there for the duration
selected, a cut-out will be performed.
Description of choice:
Select for how long the frequency converter is
to able to keep up with the output current at the
current limit I before it cuts out.
LIM
In OFF mode, parameter 412 Trip delay overcurrent ,
I is inactive, i.e. cut-outs are not performed.
LIM
Feedback signals in open loop
Normally, feedback signals and thus feedback
parameters are only used in Closed loop operation;
in VLT 6000 HVAC units, however, the feedback
parameters are also active in Open loop operation.
In Open loop mode, the feedback parameters can
be used to show a process value in the display.
If the present temperature is to be displayed, the
temperature range can be scaled in parameters
413/414 Minimum/ Maximum feedback, and the unit
(°C, °F) in parameter 415 Process units.
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.61.A5.02 - VLT is a registered Danfoss trademark
LIM
60 sec
(parameter
LIM
®
VLT 6000 HVAC Series
413 Minimum feedback , FB
(MIN. FEEDBACK)
Value:
-999,999.999 - FB
MAX
Function:
Parameters 413 Minimum feedback, FB
414 Maximum feedback, FB
scale the display indication, thereby ensuring that
it shows the feedback signal in a process unit
proportionally to the signal at the input.
Description of choice:
Set the value to be shown on the display at minimum
feedback signal value (par. 309, 312, 315 Min.
scaling) on the selected feedback input (parameters
308/311/314 Analog inputs).
414 Maximum feedback, FB
(MAX. FEEDBACK)
Value:
FB - 999,999.999
MIN
Function:
See the description of par. 413 Minimum
feedback, FB .
MIN
Description of choice:
Set the value to be shown on the display when
maximum feedback (par. 310, 313, 316 Max. scaling)
has been achieved at the selected feedback input
(parameters 308/311/314 Analoge inputs).
415 Units relating to closed loop
(REF. / FDBK. UNIT)
Value:
No unit
%
rpm
ppm
pulse/s
l/s
l/min
l/h
kg/s
kg/min
kg/h
3
m /s
3
m /min
3
m /h
m/s
MIN
0.000
and
MIN
are used to
MAX
MAX
100.000
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
