0-f 0-20 mA and
MAX
0-f 4-20 mA and
MAX
0-f 0-32000 p which generates an output signal
MAX
proportional to the output frequency in the interval 0 -
f (parameter 202 Output frequency, high limit, f
MAX
External Ref - Ref
min max
External Ref - Ref
min max
External Ref - Ref
min max
generates an output signal proportional to the resulting
reference value in the interval Minimum reference, Ref
- Maximum reference, Ref
MAX
FB -FB 0-20 mA and
MIN MAX
FB -FB 4-20 mA and
MIN MAX
FB -FB 0-32000 p, an output signal
MIN MAX
proportional to the reference value in the interval
Minimum feedback, FB
MIN
FB (parameters 413/414) is obtained.
MAX
0 - I 0-20 mA and
VLT, MAX
0 - I 4-20 mA and
VLT, MAX
0 - I 0-32000 p, an output signal
VLT, MAX
proportional to the output current in the interval
0 - I is obtained.
VLT,MAX
0 - P 0-20 mA and
NOM
0 - P 4-20 mA and
NOM
0 - P 0-32000p, which generates an
NOM
output signal proportional to the present output
power. 20 mA corresponds to the value set in
parameter 102 Motor power, P
0.0 - 100.0% 0 - 20 mA and
0.0 - 100.0% 4 - 20 mA and
0.0 - 100.0% 0 - 32.000 pulses which generates an
output signal proportional to the value (0.0-100.0%)
received by serial communication. Writing from Serial
communication is done to parameter 364 (terminal
42) and 365 (terminal 45). This function is limited to
the following protocols: FC bus, Profibus, LonWorks
FTP, DeviceNet, Metasys N2 and Modbus RTU.
Fire Mode active is indicated on the output when
activated via input 16 or 17.
Fire Mode bypass is indicated on the output
when Fire Mode has been active and a certain trip
occurred (please see description of Fire Mode). A
= factory setting. () = display text [] = value for use in communication via serial communication port
110
).
MAX
0-20 mA and
4-20 mA and
0-32000 p which
MIN
(parameters 204/205).
- Maximum feedback,
.
M,N
®
VLT 6000 HVAC Series
delay for this indication can be programmed in
parameter 432. Please select Fire Mode bypass in
parameter 430 to enable this function.
320 Terminal 42, output, pulse scaling
(AO 42 PULS SCALE)
Value:
1 - 32000 Hz
Function:
This parameter allows scaling of the pulse output signal.
Description of choice:
Set the desired value.
321 Terminal 45, output
(AO 45 FUNCTION)
Value:
See description of parameter 319 Terminal 42, Output.
Function:
This output can function both as a digital or an analog
output. When used as a digital output (data value
[0]-[26]) it generates a 24 V (max. 40 mA) signal. For
the analog outputs (data value [27] - [41]) there is a
choice of 0-20 mA, 4-20 mA or a pulse sequence.
Description of choice:
See description of parameter 319 Terminal 42, Output.
