Programming
Using the [EXTEND MENU] key, it
is possible to have access to all
the parameters for the frequency
converter.

Operation and Display 001-017

This parameter group allows to set up parameters
such as language, display readout and the possibility of
making the function keys on the control unit inactive.
001 Language
(LANGUAGE)
Value:
English (ENGLISH)
German (DEUTSCH)
French (FRANCAIS)
Danish (DANSK)
Spanish (ESPAÑOL)
Italian (ITALIANO)
Swedish (SVENSKA)
Dutch (NEDERLANDS)
Portuguese (PORTUGUESA)
Finnish (SUOMI)
State when delivered may vary from factory setting.
Function:
The choice in this parameter defines the language
to be used on the display.
Description of choice:
There is a choice of the languages indicated.

The Setup configuration

The frequency converter has four Setups (parameter
Setups) that can be programmed independently
of each other. The active Setup can be selected
in parameter 002 Active Setup. The active Setup
number will be shown in the display under "Setup".
It is also possible to set the frequency converter to
Multi-Setup to allow switching of Setups with the
digital inputs or serial communication.
Setup shifts can be used in systems where, one Setup
is used during the day and another at night.
Parameter 003 Copying of Setups enables copying
from one Setup to another.
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.61.A5.02 - VLT is a registered Danfoss trademark
®
VLT 6000 HVAC Series
By means of parameter 004 LCP copy, all Setups
can be transferred from one frequency converter
to another by moving the control panel. First all
parameter values are copied to the control panel. This
can then be moved to another frequency converter,
where all parameter values can be copied from the
control unit to the frequency converter.
002 Active Setup
(ACTIVE SETUP)
Value:
Factory Setup (FACTORY SETUP)
Setup 1 (SETUP 1)
Setup 2 (SETUP 2)
Setup 3 (SETUP 3)
Setup 4 (SETUP 4)
MultiSetup (MULTI SETUP)
[0]
Function:
[1]
The choice in this parameter defines the Setup number
[2]
you want to control the functions of the frequency
[3]
converter. All parameters can be programmed in four
[4]
individual parameter Setups, Setup 1 - Setup 4.
[5]
In addition, a pre-programmed Setup called the
[6]
Factory Setup exists. This only allows specific
[7]
parameters to be changed.
[8]
[9]
Description of choice:
Factory Setup [0] contains the parameter values pre-set
at the factory. Can be used as a data source if the
other Setups are to be returned to a common state. In
this case Factory Setup is selected as the active Setup.
Setups 1-4 [1]-[4] are four individual Setups that
can be selected as required.
MultiSetup [5] is used if remote switching between
different Setups is required. Terminals 16/17/29/32/33
and the serial communication port can be used
for switching between Setups.
[0]
[1]
[2]
[3]
[4]
[5]
79
