Technical data, mains supply 3x380-460V
According to international requirements
Output current
Output power
Typical shaft output
Typical shaft output
Max. cable cross-section to
motor and DC-bus, IP 20
Max. cable cross-section to
motor and DC-bus, IP 54
Min. cable cross-section to
motor and DC-bus
Max. input current
(RMS)
Max. cable cross-section
power, IP 20
Max. cable cross-section
power, IP 54
Max. pre-fuses
Efficiency at rated frequency
Weight IP 20
Weight IP 54
Power loss at max. load.
Enclosure
1. For type of fuse, see section Fuses.
2. American Wire Gauge.
3. Measured using 30 m screened motor cables at rated load and rated frequency.
4. Min. cable cross-section is the smallest cable cross-section allowed to be fitted on the terminals. Max. cable
cross section is the maximum possible cable cross section that can be fitted on the terminals.
Always comply with national and local regulations on min. cable cross-section.
MG.61.A5.02 - VLT is a registered Danfoss trademark
®
VLT 6000 HVAC Series
VLT type 6016
I [A] (380-440 V) 24.0
VLT,N
I (60 s) [A]
VLT, MAX
26.4
(380-440 V)
I [A] (441-460 V) 21.0
VLT,N
I (60 s) [A]
VLT, MAX
23.1
(441-460 V)
S [kVA] (400 V) 17.3
VLT,N
S [kVA] (460 V) 16.7
VLT,N
P [kW] 11
VLT,N
P [HP] 15
VLT,N
16/6
2 2) 4)
[mm ]/[AWG]
16/6
2 2) 4)
[mm ]/[AWG] 10/8
I [A] (380 V) 24.0
L,N
I [A] (460 V) 21.0
L,N
16/6
2 2) 4)
[mm ]/[AWG]
16/6
1)
[-]/UL [A] 63/40
0.96
[kg] 21
[kg] 41
[W] 419
6022 6027 6032
32.0 37.5 44.0
35.2 41.3 48.4
27.0 34.0 40.0
29.7 37.4 44.0
23.0 27.0 31.6
21.5 27.1 31.9
15 18.5 22
20 25 30
16/6 16/6 35/2
16/6 16/6 16/6
10/8 10/8 10/8
32.0 37.5 44.0
27.6 34.0 41.0
16/6 16/6 35/2
16/6 16/6 16/6
63/40 63/50 63/60
0.96 0.96 0.96
21 22 27
41 42 42
559 655 768
IP 20/ IP 54
6042
61.0
67.1
52.0
57.2
43.8
41.4
30
40
35/2
35/2
10/8
60.0
53.0
35/2
35/2
80/80
0.96
28
54
1065
