Danfoss VLT 6000 series Operating Instructions Manual page 42

Mechanical dimensions
All the below listed measurements are in mm.
VLT Type
IP 00 525 - 600 V
6102 - 6172
6222 - 6402
6502 - 6652
IP 20/NEMA 1 525 - 600 V
6002 - 6011
6016 - 6027
6032 - 6042
6052 - 6072
6102 - 6172
6222 - 6402
6502 - 6652
IP 54 525 - 600 V
6102 - 6172
6222 - 6402
6502 - 6652
aa: Minimum space above enclosure
bb: Minimum space below enclosure
1) With disconnect add 44 mm.
42
A B C
1046 408 373
1327 408 373
1547 585 494
395 220 200
560 242 260
700 242 260
800 308 296
1208 420 373
1588 420 373
2000 600 494
1208 420 373
1588 420 373
2000 600 494
MG.61.A5.02 - VLT is a registered Danfoss trademark
®
VLT 6000 HVAC Series
a b
1)
1001 304
1)
1282 304
1)
1502 304
384 200
540 200
680 200
780 270
1)
1154 304
1)
1535 304
1)
- -
1)
1154 304
1)
1535 304
1)
- -
aa/bb Type
225 J
225 J
225 J
100 C
200 D
200 D
200 D
225 J
225 J
225 H
225 J
225 J
225 H
