Danfoss VLT 6000 series Operating Instructions Manual page 81

005 Max. value of user-defined readout
(CUSTOM READOUT)
Value:
0.01 - 999,999.99
Function:
This parameter allows a choice of the max. value
of the user-defined readout. The value is calculated
on the basis of the present motor frequency and the
unit selected in parameter 006 Unit for user-defined
readout. The programmed value is reached when
the output frequency in parameter 202 Output
frequency high limit, f
MAX
decides whether the ratio between output frequency
and readout is linear, square or cubed.
Description of choice:
Set the required value for max. output frequency.
006 Unit for user-defined readout
(CUST. READ. UNIT)
1
No unit [0]
1
% [1]
1
rpm [2]
1
ppm [3]
1
pulse/s [4]
1
l/s [5]
1
l/min [6]
1
l/h [7]
1
kg/s [8]
1
kg/min [9]
1
kg/h [10] ft
3 1
m /s [11] ft
3 1
m /min [12] ft/s
3 1
m /h [13] in wg
1
m/s [14] ft wg
2
mbar [15] PSI
2
bar [16] lb/in
2
Pa [17] HP
2
kPa [18]
2
MWG [19]
3
kW [20]
Flow and speed units are marked with 1.
Pressure units with 2, and power units with
3. See figure in next column.
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.61.A5.02 - VLT is a registered Danfoss trademark
100.00
is reached. The unit also
1
GPM
1
gal/s
1
gal/min
1
gal/h
1
lb/s
1
lb/min
1
lb/h
1
CFM
3 1
ft /s
3 1
ft /min
3 1
/h
3 1
/min
1
2
2
2
2
3
®
VLT 6000 HVAC Series
Function:
Select a unit to be shown in the display in connection
with parameter 005 Max. value of user-defined readout.
If units such as flow or speed units are selected, the
ratio between readout and output frequency
[21]
will be a linear one.
[22]
If pressure units are selected (bar, Pa, MWG, PSI,
[23]
[24]
etc.), the ratio will be square. If power units (HP,
[25]
kW) are selected, the ratio will be cubed.
[26]
The value and the unit are shown in display mode
[27]
whenever User-defined readout [10] has been selected
[28]
[29]
in one of parameters 007-010 Display readout.
[30]
[31]
Description of choice:
[32]
Select the required unit for User-defined readout.
[33]
[34]
[35]
[36]
007 Large display readout
[37]
[38]
(LARGE READOUT)
Value:
Resulting reference [%] (REFERENCE [%])
Resulting reference [unit] (REFERENCE [UNIT])
Frequency [Hz] (FREQUENCY [HZ])
% of maximum output frequency [%]
(FREQUENCY [%])
Motor current [A] (MOTOR CURRENT [A])
Power [kW] (POWER [KW])
Power [HP] (POWER [HP])
Output energy [kWh] (ENERGI [UNIT])
Hours run [Hours] (OURS RUN [H])
User-defined readout [-]
(CUSTOM READ.[UNITS]))
Setpoint 1 [unit] (SETPOINT 1 [UNITS])
Setpoint 2 [unit] (SETPOINT 2 [UNITS])
Feedback 1 (FEEDBACK 1 [UNITS])
Feedback 2 (FEEDBACK 2 [UNITS])
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
81
