Danfoss VLT 6000 series Operating Instructions Manual page 106

309 Terminal 53, min. scaling
(AI 53 SCALE LOW)
Value:
0.0 - 10.0 V
Function:
This parameter is used for setting the signal value
that has to correspond to the minimum reference
or the minimum feedback, parameter 204 Minimum
reference, Ref /413 Minimum feedback, FB
MIN
Reference handling or Feedback handling.
Description of choice:
Set the required voltage value.
For reasons of accuracy, voltage losses in long
signal lines can be compensated for.
If the time-out function is to be applied (parameters
317 Time out and 318 Function after time out),
the value must be set to > 1 V.
310 Terminal 53, max. scaling
(AI 53 SCALE HIGH)
Value:
0.0 - 10.0 V
Function:
This parameter is used for setting the signal value that
has to correspond to the maximum reference value
or the maximum feedback, parameter 205 Maximum
reference, Ref /414 Maximum feedback, FB
MAX
See Reference handling or Feedback handling.
Description of choice:
Set the required voltage value.
For reasons of accuracy, voltage losses in long
signal lines can be compensated for.
311 Terminal 54, analog input voltage
(AI [V] 54 FUNCT.)
Value:
See description of parameter 308.
Function:
This parameter chooses between the different functions
available for the input, terminal 54.
Scaling of the input signal is done in parameter
312 Terminal 54, min. scaling and in parameter
313 Terminal 54, max. scaling.
Description of choice:
See description of parameter 308.
= factory setting. () = display text [] = value for use in communication via serial communication port
106
VLT
For reasons of accuracy, voltage losses in long
signal lines should be compensated for.
0.0 V
312 Terminal 54, min. scaling
(AI 54 SCALE LOW)
Value:
0.0 - 10.0 V
. See
MIN
Function:
This parameter is used for setting the signal value
that corresponds to the minimum reference value or
the minimum feedback, parameter 204 Minimum
reference, Ref
See Reference handling or Feedback handling.
Description of choice:
Set the required voltage value.
For reasons of accuracy, voltage losses in long
signal lines can be compensated for.
If the time-out function is to be applied (parameters
317 Time out and 318 Function after time out),
the value must be set to > 1 V.
10.0 V
313 Terminal 54, max. scaling
(AI 54 SCALE HIGH)
Value:
0.0 - 10.0 V
.
MAX
Function:
This parameter is used for setting the signal value
that corresponds to the maximum reference value or
the maximum feedback, parameter 205 Maximum
refe-rence, Ref
See Reference handling or Feedback handling.
Description of choice:
Set the required voltage value.
For reasons of accuracy, voltage losses in long
signal lines can be compensated for.
No operation
314 Terminal 60, analogue input current
(AI [MA] 60 FUNCT.)
Value:
See description of parameter 308.
Function:
This parameter allows a choice between the different
functions available for the input, terminal 60.
