Rear Panel Connections
The instrument has the following connections on the rear panel:
On/Off
Main Power Socket
USB port
Instrument Name Plate
The instrument name plate is located under the main power socket. The company
information on the top differs, depending upon where it is purchased. The nameplate
also shows the model name, the model (part) number, and the serial number.
Use the provided power cord or a similarly-rated replacement cord only.
Bio-Plex Pro and Bio-Plex Pro II Wash Stations
VAF
About the Instrument
Inlets for Liquid Channels 1 + 2
Vacuum Tubing
Ports (Bio-Plex Pro
II only)
Waste Tube
39
