Defining New Programs

Define/Edit a Program

54
DEFINE EDIT
< > EXIT OK
PROG1:
- + EXIT OK
NAME:EXAMPLE
567890, , ABCDE
PLATE MODE
- + EXIT OK
Plate 1, GRE96ft
- + EXIT OK
NO. OF CYCLES 1
- + EXIT OK
C1 P1 ASP
- + EXIT OK
C1 P2 ASP
- + EXIT OK
C2 CYCLE
- + EXIT OK
PROGRAM END?
- + EXIT OK
FINAL ASP?
NO YES
START
< > EXIT OK
Press OK to define or edit a program on the instrument.
Press - or + to select a program position in which a new
program will be defined or select an already existing
program to edit
Enter the required name for the program (up to eight
characters). Select a character by moving it with the cursor
keys between the commas and pressing the return key
Select , to delete a character. Select
return key to save the program name and continue to
mode selection
Press - or + to select between plate or strip mode
Press - or + to select other plate types
Press - or + to select the number of cycles
(cycles can be repeated up to 9 times)
Press - or + to select the process step (ASP, DISP, WASH,
SOAK, PROGRAM END, CX CYCLE, where X is the
number of the next cycle). Press OK to define the selected
process step. Once the process step has been defined the
display appears with the step position incremented (e.g. P1
becomes P2)
Select - or + to define the next process step
Press OK to define the selected process step
To add another cycle, press + until CX CYCLE is displayed
(X is the number of the next cycle). Press OK to define the
number of cycles.
Press – or + and press OK to select PROGRAM END
to finish defining the program.
Add a final aspiration step if necessary.
The parameters for the final aspirate step can be selected.
Once the program has been defined,
the Start menu appears again.
Bio-Plex Pro and Bio-Plex Pro II Wash Stations
