Selecting and Installing a Plate Carrier

Attention!
Use only the type
of magnetic carrier
which arrived with
your instrument.
If your wash
station arrived with
version B use of
version A on your
wash station will
result in poor
assays results.
Version B is back-
compatible with
previously installed
wash stations.
Use magnetic plate carrier with:
•
Bio-Plex Pro assays
•
Bio-Plex Precision Pro™ assays
•
Any assay with MagPlex™
microspheres
Remove the standard ELISA plate.
1. Make sure the instrument is turned off.
2. Lift the manifold arm.
3. Slightly tilt the plate carrier towards the right.
4. Carefully slide the plate carrier toward the front of the instrument until it clears the guide bar.
Installing the plate carrier is the reverse of the procedure above:
1. Carefully guide the plate carrier onto the guide bar in a slightly tilted position, as shown
above.
2. Push the plate carrier completely into the instrument, so that the front of the carrier is even
with or past the Bio-Rad logo.
3. Lower the plate carrier.
4. Lower the manifold arm.
Bio-Plex Pro and Bio-Plex Pro II Wash Stations
Magnetic Plate Carrier
(Version B)
(Version A)
Prime Tray
Basic Operation and Maintenance
Vacuum Plate Carrier
Use vacuum plate carrier with:
•
Bio-Plex assays (non magnetic)
•
Any assay on Bio-Plex COOH beads
•
Any assay on MicroPlex
microspheres
Guide Bar
