MAINTENANCE/REBOOT

Users could click on "Reboot" to reboot the device, click on "Sleep" to go into sleep mode or click on
"Shutdown" to turn off the device.

CONTACTS

The users can configure LDAP client configurations under web UI->Contacts->LDAP.

CONTACTS/LDAP

Parameters
Connection Mode
Server Address
Port
Base DN
User Name
Password
LDAP Name
Attributes
LDAP Number
Attributes
LDAP Mail
Attributes
Firmware Version 1.0.1.48
http://arttel.ru/shop/videokonferentsii/grandstream-gvc3202
Descriptions
It is used to select which protocol will be used for LDAP searching, LDAP or LDAPS.
It is used to configure the URI of the LDAP (Lightweight Directory Access Protocol)
server.
It is used to configure the LDAP server port. The default LDAP port number is 389.
It is used to configure the LDAP search base. This is the location in the directory
where the search is requested to begin.
Example:
dc=grandstream, dc=com
ou=Boston, dc=grandstream, dc=com
It is used to configure the bind "Username" for querying LDAP servers. Some LDAP
servers allow anonymous binds in which case the setting can be left blank.
It is used to configure the bind "Password" for querying LDAP servers. The field can
be left blank if the LDAP server allows anonymous binds.
It is used to configure the "name" attributes of each record which are returned in the
LDAP search result. This field allows the users to configure multiple space
separated name attributes.
Example:
gn
cn sn description
It is used to configure the "number" attributes of each record which are returned in
the LDAP search result. This field allows the users to configure multiple space
separated number attributes.
Example:
telephoneNumber
telephoneNumber Mobile
It is used to configure the "mail" attributes of the each record which are returned in
the LDAP search result.
Example:
mail
GVC3200/GVC3202 Administration Guide Page 61 of 71
