Display trusted CA certificates.

Credential Storage - Install from SD Card
Install trusted certificates from SD card. If the certificate file is stored in SD card plugged in
GVC3200/GVC3202, click on this option and select the certificate file from the SD card directory to
install it to GVC3200/GVC3202.

Clear Credentials
Clear all certificates on GVC3200/GVC3202.

MAINTENANCE

UPGRADE


Firmware Upgrade and Configuration File Detection
Select when to upgrade or initiate provisioning. Users can select "Always Check When Bootup",
"When F/W Prefix/Suffix Changes" or "Skip the Firmware Check".

Firmware Upgrade Mode
Select upgrade mode for firmware upgrading. Users could set to TFTP, HTTP or HTTPS. The default
setting is HTTP.

Firmware HTTP/HTTPS Username
Type the username if the HTTP/HTTPS for the firmware server uses the user authentication mode.

Firmware HTTP/HTTPS Password
Type the password if the HTTP/HTTPS for the firmware server uses the user authentication mode.

Firmware Server Path
Configure the server path for the firmware server.

Config Upgrade Mode
Select upgrade mode for config file provisioning. Users could set to TFTP, HTTP or HTTPS. The
default setting is HTTP.

Config HTTP/HTTPS Username
Type the username if the HTTP/HTTPS for the config server uses the user authentication mode.

Config HTTP/HTTPS Password
Type the password if the HTTP/HTTPS for the config server uses the user authentication mode.

Config Server Path
Configure the server path for the config file server.

TROUBLESHOOTING


IP Ping
Type in IP address or domain name in Target Host, then press red shortcut key on the remote control
to start Ping. The ping result shows in "Output Result".
Firmware Version 1.0.1.48
http://arttel.ru/shop/videokonferentsii/grandstream-gvc3202
GVC3200/GVC3202 Administration Guide Page 21 of 71
