MEASUrement:REFLevel:ABSolute:MID2
Description
This command sets or queries the mid reference level for the "to" waveform when taking a delay
measurement, and is the 50% reference level when MEASUrement:REFLevel:METHod is set to
Absolute. Note that this command affects the results of delay measurements. This command is
equivalent to selecting Reference Levels from the Measure menu and then entering the Absolute Mid2
Ref value.
Group
Measurement
Related Commands
MEASUrement:REFLevel:METHod (see page 264)
Syntax 1
MEASUrement:REFLevel:ABSolute:MID2 <NR3>
Syntax 2
MEASUrement:REFLevel:ABSolute:MID2?
Argument
• <NR3>
This is the mid reference level, in volts. The default is 0.0 V.
Example 1
MEASUrement:REFLevel:ABSolute:MID2 0.5
This command sets the mid reference level for the delay waveform to 0.5 V.
Example 2
MEASUrement:REFLevel:ABSolute:MID2?
This query might return , indicating that the
:MEASUREMENT:REFLEVEL:ABSOLUTE:MID2 0.5000E+00
absolute mid2 reference level is set to 0.5 V.
