WFMInpre:YOFf
Description
This command sets or queries the vertical position of the incoming waveform in digitizing levels.
Variations in this number are analogous to changing the vertical position of the waveform. For those
formats in which WFMInpre:BYT_Nr is important (all nonfloating point formats), this command must take
the location of the binary point implied by BYT_NR into consideration.
Group
Waveform Transfer
Related Commands
WFMInpre:BYT_Nr (see page 480), WFMInpre:YMUlt? (see page 489), WFMOutpre:YOFf? (see page
509)
Syntax 1
WFMInpre:YOFf <NR3>
Syntax 2
WFMInpre:YOFf?
Argument
• <NR3>
This is the vertical offset in digitizing levels.
Example 1
WFMInpre:YOFf?
This query might return , indicating the vertical position of the incoming waveform in
:WFMINPRE:YOFF 25
digitizing levels.
Example 2
WFMInpre:YOFf 50
This command specifies that the zero reference for the incoming waveform is 50 digitizing levels (2
divisions) above the center of the data range.
