WFMOutpre:BIT_Nr
Description
This command sets and returns the number of bits per waveform point that outgoing waveforms contain,
as specified by the DATa:SOUrce command. Note that values will be constrained according to the
underlying waveform data. This specification is only meaningful when WFMOutpre:ENCdg is set to BIN
and WFMOutpre:BN_Fmt is set to either RI or RP.
Group
Waveform Transfer
Related Commands
DATa:SOUrce (see page 472), WFMOutpre:BN_Fmt (see page 478), WFMOutpre:ENCdg (see page
494)
Syntax 1
WFMOutpre:BIT_Nr <NR1>
Syntax 2
WFMOutpre:BIT_Nr?
Argument
• <NR1>
This number of bits per data point can be 8, 16, 32 or 64.
Example 1
WFMOutpre:BIT_Nr?
This query might return , indicating that outgoing RI or RP binary; format data
:WFMOUTPRE:BIT_NR 8
uses 8 bits per waveform point.
Example 2
WFMOutpre:BIT_Nr 16
This command sets the number of bits per waveform point to 16, for incoming RI and RP binary format
data.
