Pacific Power Source MS SERIES Operation Manual page 73

SECTION 4
PORT PIN
COM A 2
3
4
20
8
5
7
COM B 4
20
2
3
8
5
7
With the serial port, it is possible to obtain all Front Panel Display information
described in section 4.3.1.
This paragraph provides the syntax and a brief description of all MS recognized
commands.
returned messages.
Pacific Power Source ©2013
MNEMONIC DESCRIPTION
RXDA RECEIVE DATA PORT A
TXDA TRANSMIT DATA PORT A
CTSA CLEAR TO SEND PORT A
DCDA DATA CARRIER DETECT PORT A
DSRA DATA SET READY PORT A
RTSA REQUEST TO SEND PORT A
GRD GROUND PORT A
RTSB REQUEST TO SEND PORT B
DTRB DATA TERMINAL READY PORT B
TXDB TRANSMIT DATA PORT B
RXDB RECEIVE DATA PORT B
DCDB DATA CARRIER DETECT PORT B
CTSB CLEAR TO SEND PORT B
GRD GROUND
TABLE 4.6.2 SERIAL I/O CONNECTIONS
Section 4.3.1 should be reviewed for detailed descriptions of
4-33
OPERATION
Document # 126050-10 Rev E
