Table 3.6.1 Installation Wiring - Pacific Power Source MS SERIES Operation Manual

SECTION 3
Each mainframe in an MS series system will draw the following load currents:
INPUT FORM
VOLTAGE
480 DELTA
380 DELTA
240 DELTA
208 DELTA
ALL N/A
Pacific Power Source ©2013
MODEL NUMBER 3060-MS
100% RECOMMENDED
LOAD INPUT SVC.
75A
94A
150A
170A
N/A SAFETY GROUND /

TABLE 3.6.1 INSTALLATION WIRING

FIGURE 3.6 INPUT TERMINAL DETAIL
3-13
MINIMUM INPUT WIRE
SIZE@75°C (167°F)
(COPPER CONDUCTOR)
AWG
80A
100A
175A
175A
EARTH
Document # 126050-10 Rev E
INSTALLATION
2
mm
3 35
2 35
1/0 70
2/0 70
2/0 70
