SECTION 3
3.9

ELECTRICAL SURVEY CHECKLIST

This paragraph provides a comprehensive checklist to be performed prior to first
time power-up of the MS-Series Power Source.
All work must be performed in accordance with applicable local, state, and
national electrical codes. In the event of conflict between this document and the
aforementioned codes, the codes shall be observed. It is requested that in the
event of conflict, the factory be notified.
1. Check input service, voltage and frequency, with the service
listed on the Cabinet Identification Plate on the upper rear of the
cabinet.
2. Check input service ratings. Circuit breakers and wiring to be
sized in accordance with currents listed in Section 3.0. Circuit
breaker time-overload curves should be compatible with
published curves on the Cabinet.
3. Safety wiring should be sized in accordance with currents listed
in Section 3.6. Ground for the Cabinet shall be connected to the
Cabinet from the building ground.
4. All power input and output wiring shall be run in individual
conduits. All control wiring shall be contained in separate conduit
runs.
5. Only one neutral point is to be used by the cabinet. Input neutral
is not connected and is not required. Output neutral shall be
connected at the output neutral terminal. Refer to Figure 3.5.
6. Verify that all pressure terminations are tightened per
specifications listed in Section 3.6 and 3.7.
FIGURE 3.9 ELECTRICAL SURVEY CHECKLIST
Pacific Power Source ©2013
CHECK AT RIGHT WHEN CONFIRMED:
3-21
INSTALLATION
Document # 126050-10 Rev E
