Pacific Power Source MS SERIES Operation Manual page 129

Appendix A
FIGURE A.1 3060-MS MAINFRAME MAINTENANCE/SERVICEABLE PARTS (CONT)
ITEM DESCRIPTION
35 FUSE HOLDER, MODULAR STUD TYPE
36 FUSE 300A @ 500VDC
37 CAP., 12000uF, 250V ALUM. ELECTROLYTIC
38 DUAL DIODE, 160A @ 800V
39 RESISTOR, 47K, 2W, 5%
40 RESISTOR, 250 OHM, 225W
41 RESISTOR MOUNTING BRACKET
42 CONTROL PCB ASSEMBLY
43 MODULATOR PCB ASSEMBLY
44 DISPLAY PCB ASSEMBLY
45 DISCHARGE PCB ASSEMBLY
46 LOW VOLTAGE PCB ASSEMBLY
47 INVERTER ASSEMBLY
48 CONTACTOR, 3 POLE, 120VAC COIL
49 CKT BKR, 3POLE, 175A, 230VAC (CODE U)
NOTE: QUANTITIES IN BRACKETS [ ] ARE FOR OPTIONAL INPUT VOLTAGE AND OUTPUT BREAKER
CONFIGURATIONS. REFER TO THE SETUP AND INSTALLATION SECTIONS FOR MORE
INFORMATION.
FIGURE A.2 3060-MS INVERTER ASSEMBLY MAINTENANCE/SERVICEABLE
ITEM DESCRIPTION
1 INDUCTOR, 250uH @ 16A
2 FAN,6.75" DIA.,240CFM,120V,50/60HZ
3 CURRENT TRANSDUCER MODULE,200A,50A:1V
4 THERMOSTATIC SWITCH,CLOSE @ 180 DEG.F
5 CAP., DISC,0.05uF @ 500V, TYPE Z5U
6 CAP., 10uF,400VDC,20% POLYPROP
7 CAP., 3uF,400V FEED THROUGH,MYLAR
8 TOROID CORE, 1.3 O.D. X 0.64 I. D.
9 TRANSISTOR, IGBT, 300A, 600V
10 RESISTOR,10 OHM,50W,5%,CHASSIS MOUNT
11 DRIVER PCB ASSEMBLY
12 SNUBBER PCB ASSEMBLY
Pacific Power Source ©2013
PARTS
RMS
- 2 -
QTY P/N
18 712040
2 712042
10 720219-12
6 743009
10 760053-47
2 769990-056
4 769990-057
1 126070 or
126079
1 126071
1 126072 or
126172
1 126075
1 126074
3 126225
1 717067
[1] 716048
QTY P/N
12 530014
2 703106
2 703130
2 710039
2 720023-50
8 720096-10
3 720545-30
6 732004
4 740039
4 760180-10
1 126270
2 126272
Document # 126050-10 Rev E
CKT.
SYMBOL
F10-11
C30-39
BR1-6
R30-39
R4,5
S3
CB2
[OPTIONAL -
OUTPUT]
CKT. SYMBOL
L1-12
B1-2
CT1-2
TAS1-2
C14-15
C1-8
C11-13
L13-18
Q1-4
R1-6
