POWER SUPPLY UNIT INSTALLATION

Detail of the TF-104 power supply unit installation:

The power supply unit can be mounted onto a DIN rail (3 elements) by applying slight pressure.
To remove the transformer from the rail, use a flat screwdriver and lever it off, as shown in
the drawing.

LOCK RELEASE INSTALLATION

Lock release
If the lock release is to be fitted to a metal door, use a Ø3.5mm
drill bit and thread the hole made.
For wooden doors, use a Ø3mm drill bit.
IMPORTANT:
MODULE
The self-testing LEDs are located on the upper right side of the front of
the module.
Standby
mode
Install the transformer in a dry and protected location.
To wall mount the transformer, position the
fastening tabs. Drill two 6mm diameter
holes and insert the wall plugs.
Fix the transformer with the
specified screws.
the access control module is supplied with two varistors. If
connecting an AC lock release to one of the outputs, fit the
varistor supplied directly to the lock release terminals to
ensure that the module functions
Operation
Normal
Lock
Correct code
Wrong code
Normal
Confirm field
Confirm sequence
Wrong code
Please note that current regulations stipulate that
the transformer must be protected by a circuit breaker.
correctly.
Red LED Green LED
On
Rapid blink
On On (1 second)
4 rapid blinks
Slow blink
Slow blink 2 rapid blinks
Slow blink 4 rapid blinks
4 rapid blinks
DIN 46277
DIN-7972
M 4 x 8
DIN-963
