golmar Nexa Modular Gb2 User Manual

golmar Nexa Modular Gb2 User Manual

Audio and video door entry system, 2-wire
Hide thumbs Also See for Nexa Modular Gb2:
Table of Contents

Advertisement

Quick Links

See also: Quick Manual
TECHNOLOGY
Audio and Video
Door Entry System
Nexa Modular Gb2
2-Wire
Code 50121981
REV.0 1
2 7
T
632 B2A
G
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Nexa Modular Gb2 and is the answer not in the manual?

Questions and answers

Related Manuals for golmar Nexa Modular Gb2

Summary of Contents for golmar Nexa Modular Gb2

  • Page 1 TECHNOLOGY Audio and Video Door Entry System Nexa Modular Gb2 2-Wire Code 50121981 REV.0 1 632 B2A...

  • Page 2: Table Of Contents

    NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING INTRODUCTION First and foremost we would like to thank you for purchasing this product. Our commitment to achieving the satisfaction of customers like you is manifested through our ISO-9001 certification and the manufacture of products like the one you have just purchased.

  • Page 3: Safety Precautions

    NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING SAFETY PRECAUTIONS Always disconnect the power supply before installing or making modifications to the devices. The fitting and handling of these devices must be carried out by authorised personnel The wiring must run at least 40 cm away from any other wiring.

  • Page 4: Description Of The Nexa Modular Door Panel

    NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING DESCRIPTION OF THE NEXA MODULAR DOOR PANEL Description of the door panel: Door panel component assembly drawing. Electronic Embedding boxes Frame modules Aluminium panel modules Description of the door panel.

  • Page 5: Description Of The El632 Gb2A/El642 Gb2A Sound Module

    NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING DESCRIPTION OF THE EL632 GB2A/EL642 GB2A SOUND MODULE Description of the EL632 GB2A/EL642 GB2A sound module: Front. Colour television camera (EL632 GB2A sound module only) LEDs (visual signals for people with impaired hearing).

  • Page 6: Description Of The El610D Button Modules

    NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING DESCRIPTION OF THE EL610D BUTTON MODULE Description of the EL610D button module: Front. Module buttons (x10). Back. Button connector input/output (x3). DIP switch (button call code). Button number.

  • Page 7: Positioning The Embedding Box

    NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING INSTALLATION OF THE DOOR PANEL Positioning the embedding box: 1850 1650 1450 Make a hole in the wall to position the top of the door panel at a height of 1.65m.

  • Page 8: Fitting The Embedding Box

    NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING INSTALLATION OF THE DOOR PANEL Fitting the embedding box: Pass the cable through the hole made in the embedding box. Embed the box and ensure that it is level and flush. Once the embedding box is positioned, remove the protective stickers from the door panel's fixing holes.

  • Page 9: Fastening The Frame To The Embedding Box

    NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING INSTALLATION OF THE DOOR PANEL Fastening the frame to the embedding box: Insert the spring hinge which attaches to the product in the embedding box, as shown in the drawing.

  • Page 10: Connecting The Buttons To The Rap-610D Short Connection Cable

    NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING INSTALLATION OF THE DOOR PANEL Connecting the buttons to the RAP-610D short connection cable: Use the RAP-610D connection cable to connect the buttons between the sound module and the EL610D button module and between EL610D button modules when the distance between modules to be connected is greater due to the composition of the door panels.

  • Page 11: Configuring Double Button Module Codes

    NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING INSTALLATION OF THE DOOR PANEL Configuring double button module codes: EL632 GB2A Front Back VESTA2 VESTA2 Monitor Code Monitor Code Monitor Code C1 NA1 C2 AP+ AP- P1 P2 BUSBUS Relé...

  • Page 12: Configuring Single Button Module Codes

    NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING INSTALLATION OF THE DOOR PANEL Configuring single button module codes: EL632 GB2 EL632 GB2A Front Back VESTA2 Monitor Code C1 NA1 C2 AP+ AP- P1 P2 BUSBUS 0/32 Relé 1 Relé...
  • Page 13 NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING INSTALLATION OF THE DOOR PANEL Continued from previous page. EL610D Monitor Code Not used Not used Not used Not used Not used Not used Not used Not used Not used...

  • Page 14: Configuring The Button Code (Operating Mode 2, Audio Only Up To 128 Telephones/Apartments)

    NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING INSTALLATION OF THE DOOR PANEL Configuring the button code (audio only installation up to 128 telephones/apartments): The EL610D button module needs to be configured in order to assign a call code to the buttons.
  • Page 15 NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING INSTALLATION OF THE DOOR PANEL Continued from previous page. EL610D button module Single button module codes DIP switch Button code P3 P5 P7 P9 Dip1 Dip2 Dip3 Dip4 Dip5 Dip6 Dip7 Dip8...

  • Page 16: Configuring Double Button Module Codes

    NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING INSTALLATION OF THE DOOR PANEL Configuring double button module codes (up to 128 telephones/apartments): EL632 GB2A Front Back EL642 GB2A T-562 T-562 Telephone code Telephone code Telephone code C1 NA1...
  • Page 17 NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING INSTALLATION OF THE DOOR PANEL Continued from previous page. EL610D Telephone code Telephone code Telephone code IMPORTANT: The T562/TNHEA telephone's DIP 10 should be set to ON. Continued overleaf...
  • Page 18 NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING INSTALLATION OF THE DOOR PANEL Continued from previous page. EL610D Telephone code Telephone code Telephone code Code 78 Code 78 Code 76 Code 76 Code 74 Code 74 Code 72...
  • Page 19 NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING INSTALLATION OF THE DOOR PANEL Continued from previous page. EL610D Telephone code Telephone code Telephone code Not used Not used Not used Not used Not used Sin uso IMPORTANT: The T562/TNHEA telephone's DIP 10 should be set to ON.

  • Page 20: Configuring Single Button Module Codes

    NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING INSTALLATION OF THE DOOR PANEL Configuring single button module codes (up to 71 telephones/apartments): EL632 GB2A Front Back EL642 GB2A T-562 Telephone code C1 NA1 C2 AP+ AP- P1 P2 BUSBUS...
  • Page 21 NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING INSTALLATION OF THE DOOR PANEL Continued from previous page. EL610D Telephone code Not used Not used Not used Not used Not used Not used Not used Not used Not used...
  • Page 22 NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING INSTALLATION OF THE DOOR PANEL Continued from previous page. EL610D Telephone code Not used Not used Not used Not used Not used Not used Not used Not used Not used...
  • Page 23 NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING INSTALLATION OF THE DOOR PANEL Continued from previous page. EL610D Telephone code Code 60 Not used Not used Code 59 Not used Not used Code 58 Not used Not used...

  • Page 24: Description Of The Dip Switch

    NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING INSTALLATION OF THE DOOR PANEL Description of the sound module DIP switch: The DIP switch is located on the left side of the back of the module. Door panel address: DIP switches: 1 and 2 OFF (address 1), 1 ON and 2 OFF (address 2), 1 OFF and 2 ON (address 3), 1 and 2 ON (address 4).

  • Page 25: Description Of The Vocal Synthesis (Audible Signals On The Door Panel)

    NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING INSTALLATION OF THE DOOR PANEL Description of the vocal synthesis (audible signals on the door panel): Audible signals on the door panel for people with impaired vision. If vocal synthesis is enabled on the sound module (see page 24-25 for configuration), the following voice messages can be heard on the door panel: While calling: “Call is in progress”.

  • Page 26: Adjusting The Vocal Synthesis Volume

    NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING INSTALLATION OF THE DOOR PANEL Adjusting the vocal synthesis volume: If after starting the system the vocal synthesis volume of the door panel seems inadequate, follow these steps: Disconnect the door panel's power supply.

  • Page 27: Closing The Frame And Inserting The Button Identification Labels

    NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING INSTALLATION OF THE DOOR PANEL Continued from previous page. Building mode: Set DIP 4 on the sound module to ON (see page 24). Up to 23 monitors and apartments with a Vesta2 monitor per installation.

  • Page 28: Mounting The Door Panel/Double Door Panel Modules And Closing The Door Panel

    NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING INSTALLATION OF THE DOOR PANEL Mounting the modules of a door panel: Insert a clip-on cover into the side profiles (from the bottom) and fix it using the screws specified (step 1 ) and then insert the module (step 2 ).
  • Page 29 NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING INSTALLATION OF THE DOOR PANEL Mounting the modules of a double door panel: Mount door panel A (step 1 ) as described in 'Mounting the modules of a door panel' (see page 28), taking into account that the bar connecting panel A and panel B must be a door panel UNE rod, see drawing below.
  • Page 30 NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING INSTALLATION OF THE DOOR PANEL Closing the door panel: Fix the door panel to the embedding box using the screws supplied. To complete the fitting of the panel, attach the clip-on covers by positioning one end and then applying slight pressure to the other end until they clip into place.

  • Page 31: Installing The Power Supply Unit (Fa-Gb2/A) And Lock Release

    NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING INSTALLATION OF THE POWER SUPPLY UNIT Installing the FA-GB2/A power supply unit: Install the power supply unit in a dry and protected place free from the risk of water leaks or sprays.

  • Page 32: Wiring Diagrams

    NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING WIRING DIAGRAMS: Video door entry system with 23 VESTA2 monitors, 6 DP-GB2A distributors and Golmar d.c. lock release. VESTA2 Master ( ) 2 ( APARTMENT End of line VESTA2...
  • Page 33 NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING WIRING DIAGRAMS: Video door entry system with 23 VESTA2 monitors, 12 D2L-GB2 distributors and Golmar d.c. lock release. VESTA2 Master End of line ( ) 3 APARTMENT VESTA2 VESTA2...
  • Page 34 NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING WIRING DIAGRAMS: Mixed installation: Up to 23 elements (Vesta2 monitors/T562 telephones), 6 DP-GB2A distributors and d.c. lock release. Additional telephone (in the same apartment) End of line VESTA2 T-562...
  • Page 35 NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING WIRING DIAGRAMS: Video door entry system with 18 VESTA7 monitors, 5 DP-GB2A distributors and Golmar d.c. lock release. End of line VESTA7 VESTA7 Master Master ( ) 2 (...
  • Page 36 NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING WIRING DIAGRAMS: Video door entry system with 18 VESTA7 monitors, 9 D2L-GB2 distributors and Golmar d.c. lock release. VESTA7 VESTA7 End of line Master Master ( ) 3 ( ) 3...
  • Page 37 NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING WIRING DIAGRAMS: Mixed installation: Up to 18 elements (Vesta7 monitors/Nhea hands-free audio terminals), 5 DP-GB2A distributors and d.c. lock release. End of line Additional hands-free audio terminal (in the same apartment)
  • Page 38 NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING WIRING DIAGRAMS: Audio door entry system with 32 apartments/T562 GB2 telephones and Golmar d.c. lock release: T-562 GB2 Master APARTMENT T-562 GB2 Master APARTMENT T-562 GB2 Master APARTMENT Mains...
  • Page 39 NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING WIRING DIAGRAMS: Audio door entry system with 32 apartments/NHEA hands-free audio terminals and Golmar d.c. lock release: NHEA Master APARTMENT NHEA Master APARTMENT NHEA Master APARTMENT Mains Distances and cross-sections:...
  • Page 40 NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING WIRING DIAGRAMS: Audio door entry system with 128 apartments/T562 GB2 telephones and Golmar d.c. lock release: (The EL632 GB2A sound module should be set to 'operating mode 2' audio only, see page 26).
  • Page 41 NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING WIRING DIAGRAMS: Audio door entry system with 128 apartments/NHEA hands-free audio terminals and Golmar d.c. lock release: (The EL632 GB2A sound module should be set to 'operating mode 2' audio only, see page 26).
  • Page 42 NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING WIRING DIAGRAMS: Video door entry system with 4 access panels, DP-GB2A distributor for door panels and Golmar d.c. lock release. Video door entry system: To the distributors (building floors)

  • Page 43: Wiring Diagrams

    NEXA MODULAR GB2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING WIRING DIAGRAMS: Connection of Golmar d.c. and a.c. lock releases. Connection of 2 DC lock releases without “AP”: Access panel Button panel Coded panel ( ) 2 To the FA-GB2/A power supply ó...
