  • Page 1 Cód. 50121535 Audio and Video door entry system (Mechanical assembly of the door panel) Nexa Modular Assembly manual Tnexa Modular ML rev.0112...

  • Page 2: Table Of Contents

    INTRODUCTION First of all we would like to thank and congratulate you for the purchase of this product manufactured by Golmar. The commitment to reach the satisfaction of our customers is stated through the ISO-9001 certification and for the manufacturing of products like this one.

  • Page 3: Door Panel Description

    DOOR PANEL DESCRIPTION Coming from previous page Door panel description. Screws of fixation of header (x4) Screws of fixation of embedding box (x2) Closing heads: 60xx Lateral rod Door panel UNE rod Grille module: N1000/AL N1110/AL 1P . N2220/AL 2P . Nexa spacer module Push buttons module: 3xxx Lateral rod (x2)

  • Page 4: Door Panel Installation

    DOOR PANEL INSTALLATION mbedding box positioning. 1850 1650 1450 The upper part of the door panel should be placed at 1,65m. height roughly. The hole dimensions will depend on the type of door panel. Modules Model NCEV90CS NCEV90C CEV90 99 mm. 328 mm.

  • Page 5: Assembly The Electronic Modules

    DOOR PANEL INSTALLATION lace the embedding box. Pass the wiring through the hole made in the bottom part of the embedding box. Level and flush the embedding box. Once the embedding box is placed, remove the protective labels from the attaching door panel holes. ssembly the electronic modules.

  • Page 6: Hold The Frame

    DOOR PANEL INSTALLATION old the frame on the embedding box. Insert the hinge that it is supplied with the product in the embedding box, as shown in the drawing. To hold the frame on the embedding box, insert the hinge in the housings arranged for this purpose in the frame, as shown in the drawing.

  • Page 7: Door Panel Assembly

    DOOR PANEL INSTALLATION oor panel assembly. Insert a header in the lateral rods (at the bottom part) and fix it with the supplied screws (step 1 ), then insert the module (step 2 ). If the door panel is more than one module insert first the lower module, see picture A .

  • Page 8: Double Door Panel Assembly

    DOOR PANEL INSTALLATION ouble door panel assembly. Assembly the door panel A (step 1 ), as it is described in page 26 "Door panel assembly". Bear in mind that the rod that will join the door panel A and door panel B have to be of the type door panel UNE rod, see picture below.

  • Page 9: Close The Door Panel

    DOOR PANEL INSTALLATION lose the door panel. fix the door panel in the embedding box with the supplied screws. Finish the door panel assembly by placing the closing heads, put the head on one side and then make a slight pressure on the other end, to its correct placement. Door panel: Double door panel:...
